Document methods.
Document methods.
static ItemRef alloc(char* path)
Create a reference to an open document.
Name | Type | Default | Description |
Return | ItemRef | Reference to the document. Release this reference as soon as possible using item::release. 0 : document not found | |
path | String or char* | - | Complete path to the document file or "Unnamed-1", ... in case of new documents. |
int main () { ItemRef d1 = document::alloc ("$DESKTOP/test.indd"); ItemRef d2 = document::alloc ("Unnamed-1"); wlog ("", "Test : %d\n", item::getint (d1)); wlog ("", "New : %d\n", item::getint (d2)); return 0; }
The UID 0 always points to a document. The examples creates an ItemRef to the document of the current frame an shows the documents name.
int main () { ItemRef docRef = item::alloc (); char docName [4000];
item::define (docRef, gFrame, 0); document::name (docName, docRef); showmessage (docName);
return 0; }
static int is_valid(ItemRef docRef)
Does the reference point to an existing document?
Name | Type | Default | Description |
Return | int | 1 : Yes, the ref points to an existing and opened document. 0 : No document referenced. Do not use this reference as to be a document. Most scripts haven't set gDocument to a valid value and using 0 as a short cut for the current front document. A call to document::is_valid will return 1 (true) even if docRef is set to 0. If you wish to do something this docRef you have to check it this way : if (document::is_valid (docRef) && docRef) .... |
|
docRef | ItemRef | - | Any ItemRef or 0 |
static ItemRef current()
Ascertain the InDesign® document of the script. The variable may not be deleted. In most cases the functions returns 0 or a reference to 0. This 0 means to work on the current front document. The get a valid reference to this this document use get_front.
Name | Type | Default | Description |
Return | ItemRef | Current InDesign® document or 0 In most cases the functions returns 0 or a reference to 0. This 0 means to work on the current front document. The get a valid reference to this this document use get_front. |
static ItemRef get_front()
Get the front document.
Name | Type | Default | Description |
Return | ItemRef | Reference to the front document. Release this reference as soon as possible using item::release. |
static int count()
How many documents are open in the moment?
Name | Type | Default | Description |
Return | int | Number of open documents |
static char* get_nth(int n, ItemRef outRef = 0)
Path or window title of n-th opened document.
Name | Type | Default | Description |
Return | char* | Path of the document file or window title in case of new documents
The return value must not be changed and will be overwritten in subsequent calls of the function. See here to learn more about functions returning r/o char* values. |
|
n | int | - | 0 based index of document |
outRef | ItemRef | 0 | If the function is executed successfully, the variable contains a reference to the opened document 0 : Ignore> otherwise: Reference object created with item::alloc |
int main () { int i; int docs = document::count ();
for (i = 0; i < docs; i++) { wlog ("", "%d : '%s'\n", i+1, document::get_nth (i)); }
return 0; }
static int select(ItemRef docRef)
Set the current front document. Since most script functions work on the current front document, you can use this call to cause your script to start the processing in another document..
The call also works in InDesign® Server.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | valid document reference |
static int select_by_name(char* pp)
Set the current front document. Most script functions are working on the current front document. So with this call you can cause your script to change its destination document. The document is selected by its name or the file path.
Name | Type | Default | Description |
Return | int | Fehlercode or 0 | |
pp | String or char* | - | Name or full path of the documents file. For unsaved new documents, the document name is used. It applies: Specification without path delimiter : search only by name Specification path delimiter : Search for the complete path |
static ItemRef create(
float width = -1.0,
float height = -1.0,
int pages = 1,
int pagesPerSpread = 1,
float scale = 1.0,
int left = 0,
int top = 0,
int right = 0,
int bottom = 0,
int columns = -1,
float gutter = 0.0,
int vertical_cols = 0,
int restartPageNums = -1,
int bindingDirection = -2,
int intent = -1,
float ml = -1.0,
float mt = -1.0,
float mr = -1.0,
float mb = -1.0 )
Create a new empty InDesign® document. The generated ItemRef must be deleted again from the script.
Name | Type | Default | Description |
Return | ItemRef | Reference to the newly created documented, with item::release to delete | |
width | float | Width of the current document page width in points | |
height | float | Height of the current document page in points | |
pages | int | Page number of the current document | |
pagesPerSpread | int | 1 | Pages per printed sheet |
scale | float | 1.0 | Current scale |
left, top, right, bottom | int | 0 | Window position and size |
columns | int | -1 | Bumber of columns -1 : ignore |
gutter | float | 0.0 | Column gutter in points, only used if columns is greeter 0. |
vertical_cols | int | 0 | Direction of columns, only used if columns is greeter 0. 1 vertical 0 horizontal |
restartPageNums | int | -1 | Restart page numbering? -1 : ignore 0 : no 1 : yes |
bindingDirection | int | -2 | page binding -2 : ignore -1 : use default 0 : left to right 1 : right to left |
intent | int | -1 | Document intention. Supported since CS5 -1 : ignore 0 : for printing 1 : for web |
ml, mt, mr, mb | float | -1.0 | Margins in points ml == -1.0 : Use default settings. |
#include "internal/types.h"
int main () { ItemRef docRef = 0;
docRef = document::create ( 595.276, 841.89, // page size 5, 2, // pages, pages per spread 1.0, // scale 0, 0, 0, 0, // window 3, 12.0, 0, // columns, gutter direction -1, // restart numbering -2, // binding direction 1, // intent 20.0, 21.0, 22.0, 23.0); // margins if (!document::is_valid (docRef)) return 0;
document::set_units (docRef, kUnitPoints, kUnitPoints);
return 0;
static ItemRef open(
char* path,
float scale = 1.0,
int left = 0,
int top = 0,
int right = 0,
int bottom = 0,
int visibility = 1,
int appendToRecent = 1,
int uiFlags = kSuppressUI,
int parenting = -1)
Open an InDesign® document. InDesign® Server ignores all visibility information (paramenter scale and following).
Name | Type | Default | Description |
Return | ItemRef | Reference to the newly created documented, with item::release to delete | |
path | String or char* | - | Complete path to the file to be opened. In case of comet_pdf, the extension indd is replace automatically by w2ml. |
scale | float | 1.0 | Current scale |
left | int | 0 | Window position |
top | int | 0 | Window position |
right | int | 0 | Window position |
bottom | int | 0 | Window position |
visibility | int | 1 | Window visible / hidden 0 : No, only use in background 1 : Yes. The document will get the new front document. Script functions working on the front document will use this document instead of the callimg document. Since v4.1 R22423 the same is true for InDesign® Server. |
appendToRecent | int | 1 | Insert the file to the Recent documents menu? 0 : No 1 : Yes |
uiFlags | int | kSuppressUI | Dialogs to show kSuppressUI :Suppress all dialogs and progress bars kMinimalUI : Even show certain dialogs kFullUI : Show all dialogs and progress bars |
parenting | int | -1 | The parenting allow a caller to specify how and where a new presentation will be created,
optionally in relation to an existing presentation. InDesing supports the following
(undocumented by Adobe) values: -1 : Ignore value 0 : InDesign® Default 1 : NewFloatingDock 2 : NewFloatingDock_ObscureRelative 3 : NewFloatingDock_DontObscureRelative 4 : AsSiblingOfRelative 5 : InNewTabGroupFromRelative 6 : InNewPaneFromRelative 7 : AsSiblingToLeftOfRelative 8 : AsRightmostChildOfParent |
Open and show a document. Alerts for missing fonts, links, ... are suppressed.
#include "internal/types.h"
int main () { ItemRef doc = document::open ("$DESKTOP/paul.indd", 1.0, 0, 0, 0, 0, 1, 1, kSuppressUI);
return 0; }
Open and show a document
#include "internal/types.h"
int main () { ItemRef doc = document::open ("$DESKTOP/paul.indd", 1.0, 0, 0, 0, 0, 1, 1, kFullUI);
return 0; }
static ItemRef open_copy(
char* path,
float scale = 1.0,
int left = 0,
int top = 0,
int right = 0,
int bottom = 0,
int visibility = 1,
int appendToRecent = 1,
int uiFlags = kSuppressUI)
Open a copy of an InDesign® document. InDesign® Server ignores all visibility information (paramenter scale and following).
Name | Type | Default | Description |
Return | ItemRef | Reference to the newly created documented, with item::release to delete | |
path | String or char* | - | Complete path to the file to be opened. |
scale | float | 1.0 | Current scale |
left | int | 0 | Window position |
top | int | 0 | Window position |
right | int | 0 | Window position |
bottom | int | 0 | Window position |
visibility | int | 1 | Window visible / hidden 0 : No, only use in background 1 : Yes. The document will get the new front document. Script functions working on the front document will use this document instead of the callimg document. |
appendToRecent | int | 1 | Insert the file to the Recent documents menu? 0 : No 1 : Yes |
uiFlags | int | kSuppressUI | Dialogs to show kSuppressUI :Suppress all dialogs and progress bars kMinimalUI : Even show certain dialogs kFullUI : Show all dialogs and progress bars |
parenting | int | -1 | The parenting allow a caller to specify how and where a new presentation will be created,
optionally in relation to an existing presentation. InDesing supports the following
(undocumented by Adobe) values: -1 : Ignore value 0 : InDesign® Default 1 : NewFloatingDock 2 : NewFloatingDock_ObscureRelative 3 : NewFloatingDock_DontObscureRelative 4 : AsSiblingOfRelative 5 : InNewTabGroupFromRelative 6 : InNewPaneFromRelative 7 : AsSiblingToLeftOfRelative 8 : AsRightmostChildOfParent |
static int set_display_name(ItemRef doc, char* name)
Set the display name of the document. Set the displayed name of a document. This name is used as the window title and as a suggestion for the filename when using File -> Save As.
The displayed name is not the filename. Changes to the display name are not applied to the document and will be lost when the document is closed.
Name | Type | Default | Description |
Return | int | ErrorCode or 0 | |
doc | ItemRef | - | Valid document reference |
name | String or char* | - | New name of the document |
Set the name of the current document
char* newName = "HelloWorld";
document::set_display_name(gDocument, newName);
static char* get_display_name(char* result, ItemRef docRef = 0)
Title of the document in the document window. In the standard case, the file name (or Unnamed-N for new documents) is used as window title. If the window title was changed by document::set_display_name, the function returns the changed window title.
Name | Type | Default | Description |
Return | String or char* (Depends on parameter result) | Window title of the document For better use of the function, result is used as the return value. |
|
result | String or char* | - | Reserved memory for result 0 : [since v4.3 R33094] Return result in a static r/o variable of the Script Engine. The variable must not be changed. The next time the function is called, the content will be overwritten! |
docRef | ItemRef | 0 | Document specification. If there is no specification, the active/uppermost document will be used. With gDocument or 0 that document will be used with which the script was started. |
static int is_opened(char* path, ItemRef docRef = 0)
Shows whether a document is opened or not.
Name | Type | Default | Description |
Return | int | 1 if the document is opened, else 0 | |
path | String or char* | - | complete path to the document. |
docRef | ItemRef | 0 | After successful return it contains a reference to the document. Must be allocated before using item::alloc |
Check whether a docuemt is already opened, and if not, open it. Be care to delete the used reference before calling document::open, this call will create a new reference.
ItemRef docRef = item::alloc (); int wasOpened = document::is_opened (path, docRef);
if (!wasOpened) { item::release (docRef); docRef = document::open (path, docRef); }
:
if (wasOpened) document::close(docRef);
static int close(
ItemRef docRef,
int saveOnClose = 1,
int uiFlags = kSuppressUI,
int allowCancel = 1,
int mode = kSchedule)
Closing a document. Closing documents can force a lot of actions on the document. InDesign® therefore schedules document closing to the next idle time. With kProcess you can force direct closing, but this may cause serious problems!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document to close 0 : front document |
saveOnClose | int | 1 | save before close? 0 : Do not save, changes are omitted 1 : Save |
uiFlags | int | kSuppressUI | Dialogs to show kSuppressUI :Suppress all dialogs and progress bars kMinimalUI : Even show certain dialogs kFullUI : Show all dialogs and progress bars |
allowCancel | int | 1 | Cancel allowed? Not supported while uiFlags kSuppressUI or mode kImmediate is set 0 : Forbidden 1 : Allowed |
mode | int | kSchedule | close mode kSchedule : Close normally on next idle time kProcess : Close right now. This may cause seriuos problems even on changed files! kImmediate : since v4.1 R24666 Close immediately. This is an attempt to circumvent the InDesign® problems with kProcess. Unfortunately, we cannot promise that this will work in every case - but it is worth a try. |
static int close_by_name(
char* docPath,
int saveOnClose = 1,
int uiFlags = kSuppressUI,
int allowCancel = 1,
int mode = kSchedule)
Closing a document. Closing documents can force a lot of actions on the document. InDesign® therefore schedules document closing to the next idle time. With kProcess you can force direct closing, but this may cause serious problems!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docPath | String or char* | - | Full path of document to close |
saveOnClose | int | 1 | save before close? 0 : Do not save, changes are omitted 1 : Save |
uiFlags | int | kSuppressUI | Dialogs to show kSuppressUI :Suppress all dialogs and progress bars kMinimalUI : Even show certain dialogs kFullUI : Show all dialogs and progress bars |
allowCancel | int | 1 | Cancel allowed? Not supported while kSuppressUI or mode kImmediate is set 0 : Forbidden 1 : Allowed |
mode | int | kSchedule | close mode kSchedule : Close normally on next idle time kProcess : Close immediatally. This may cause seriuos problems even on changed files! kImmediate : since v4.1 R24666 Close immediatally. This is an attempt to circumvent the InDesign® problems with kProcess. Unfortunately, we cannot promise that this will work in every case - but it is worth a try. |
static int save(
ItemRef docRef,
int uiFlags = kSuppressUI,
int millisec = 0,
int repeat = 0)
Saving a document.
Due to a bug in InDesign®, saved documents can come in an unsaved state after a short time. If you type in some text and save the document using Command-S very quickly you can see this behavior. Same things happens if you change some text inside a script and save the document. To get a reall saved document, you can save the document in the next idle time, and (we couldn't find out, when InDesign® fires the document changes) you can repeat saving some times. Good results we got with 300 milli seconds after idle time and 5 to 8 repetiions.
Using idle time saving means, the document is NOT saved on funtion return!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document to save 0 : front document |
uiFlags | int | kSuppressUI | Dialogs to show kSuppressUI :Suppress all dialogs and progress bars kMinimalUI : Even show certain dialogs kFullUI : Show all dialogs and progress bars Ignored by comet_pdf. |
millisec | int | 0 | Time to save the document in milli seconds after idle time starts 0 : ignore (save right now) >0 : Duration after idle time start <0 : Automatic saving of the document every millisecs Ignored by comet_pdf & Illustrator. |
repeat | int | 0 | (only if > 0) Number of tries Ignored by comet_pdf & Illustrator. |
static int saveas(
ItemRef docRef,
char* path,
int uiFlags = kSuppressUI)
Saving a document using a given destination path. The function will change the the window of the given document to the 'save as' file.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document to save as ... 0 : Current document of script |
path | String or char* | - | Complete path incl. name and extender for the new file. If the path not exists, it will created automatically. Illustrator: To save file as EPS use file extension ".eps". |
uiFlags | int | kSuppressUI | Dialogs to show kSuppressUI :Suppress all dialogs and progress bars kMinimalUI : Even show certain dialogs kFullUI : Show all dialogs and progress bars Ignored by comet_pdf and Illustrator. |
static int revert(ItemRef docRef = 0)
Revert document to last saved version.
Calls to this function may close and re-open documents. References to gFrame, gDocument, etc. will point to non-existent objects and their usage can crash InDesign® immediatelly!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode 1280 : New unsaved or unmodified document If the given document was found, the command always returns 0 in comet_pdf. |
|
docRef | ItemRef | - | Valid document 0 : Current document of script |
static char* name(char* result, ItemRef docRef = 0)
File name of the current document. For the entry a string is expected which has sufficient reserved memory (min. 256), in order to handle the result. The function will not provide any result for new unsaved documents.
Name | Type | Default | Description |
Return | String or char* (Depends on parameter result) | Name of the current document, pointer to result | |
result | String or char* | - | Reserved memory for result 0 : [since v4.3 R33094] Return result in a static r/o variable of the Script Engine. The variable must not be changed. The next time the function is called, the content will be overwritten! |
docRef | ItemRef | 0 | Document specification. If there is no specification, the active/uppermost document will be used. With gDocument or 0 that document will be used with which the script was started. |
Get the name of the current document
char name[256];
showmessage (document::name (name));
static char* path9(char* p, ItemRef docRef = 0)
File path including file name of the current document. On the Mac, the result is returned in MacOS 9 notation with drive name and ':' as path delimiter.
Yes! You wouldn't believe it: The last Mac OS 9 is over 20 years ago. But the InDesign menu 'Recent Files' and the 'Links' panel still showing Mac OS 9 paths, as well as the the InDesign SDK uses this style of paths.
For the entry a string is expected which has sufficient reserved memory (min. 1024), in order to handle the result. The function will not provide any result for new unsaved documents.
Name | Type | Default | Description |
Return | String or char* | (Depends on parameter p) Complete MacOS 9 path of the current document, pointer to p | |
p | String or char* | - | Reserved memory for the result 0 : [since v4.3 R33094] Return result in a static r/o variable of the Script Engine. The variable must not be changed. The next time the function is called, the content will be overwritten! |
docRef | ItemRef | 0 | Document specification. If the specification is missing, the active/upper document will be used. With gDocument or 0 the document will be used with which the script was started script was started. |
Get the name of the current document
char p[256];
showmessage (document::path9 (p));
static char* path(char* p, ItemRef docRef = 0)
File path including file name of the current document. For the entry a string is expected which has sufficient reserved memory (min. 1024), in order to handle the result. The function will not provide any result for new unsaved documents.
Name | Type | Default | Description |
Return | String or char* | (Depends on parameter p) Complete path of the current document, pointer to p | |
p | String or char* | - | Reserved memory for the result 0 : [since v4.3 R33094] Return result in a static r/o variable of the Script Engine. The variable must not be changed. The next time the function is called, the content will be overwritten! |
docRef | ItemRef | 0 | Specification of the document. If the specification is missing, the active/upper document will be used. With gDocument or 0 the document will be used with which the script was started. |
Get the path of the current document
char p[1024];
showmessage (document::path (p));
static char* pathX(char* p, ItemRef docRef = 0)
File path including the file name of the current document. In the path all Windows path delimiters (\) are replaced with /. This format should always then be used if the path is to be used for internal descriptions (xmlquery, soap, cscript). For the entry a string is expected which has sufficient reserved memory (min. 1024) in order to handle the result. The function will not provide any result for new unsaved documents.
Name | Type | Default | Description |
Return | String or char* | (Depends on parameter p) Complete path of the current document, pointer to p | |
p | String or char* | - | Reserved memory for the result 0 : [since v4.3 R33094] Return result in a static r/o variable of the Script Engine. The variable must not be changed. The next time the function is called, the content will be overwritten! |
docRef | ItemRef | 0 | Specification of the document. If the specification is missing, the active/upper document will be used. With gDocument or 0 the document will be used with which the script was started. |
Get the OS X path of the current document
char p[1024];
showmessage (document::pathX (p));
static char* folder(char* p, ItemRef docRef = 0)
Folder of the current document without path delimiter (: or /) at the end. For the entry a string is expected which has sufficient reserved memory (mind. 1024) in order to handle the result. The function will not provide any result for new unsaved documents.
Name | Type | Default | Description |
Return | String or char* | (Depends on parameter p) Complete path of the current document, pointer to p | |
p | String or char* | - | Reserved memory for the result 0 : [since v4.3 R33094] Return result in a static r/o variable of the Script Engine. The variable must not be changed. The next time the function is called, the content will be overwritten! |
docRef | ItemRef | 0 | Specification of the document. If the specification is missing, the active/upper document will be used. With gDocument or 0 the document will be used with which the script was started. |
Get the folder path of the current document
char p[1024];
showmessage (document::folder (p));
static char* folderX(char* p, ItemRef docRef = 0)
DEPRECATED! BPlease use the function document::path9 instead and remove the document name from this result.
static int pages(ItemRef doc = 0)
Number of pages in the document.
Name | Type | Default | Description |
Return | int | Number of pages in the given document | |
docRef | ItemRef | 0 | Specification of the document. If the specification is missing, the active/upper document will be used. With gDocument or 0 the document will be used with which the script was started. |
static int page(ItemRef docRef = 0)
Current page of a given document.
To make a page the current page, you must click at least once in the page area. A frame does not have to be selected for this, but simple scrolling to the page view is not enough! Using InDesign® Server or comet_pdf the current front page is undefined!
Name | Type | Default | Description |
Return | int | 0 : in case of any erros otherwise : 1-based current page of the given document Using InDesign® Server or comet_pdf the current front page is undefined! The function will always return 0 |
|
docRef | ItemRef | 0 | Specification of the document. If the specification is missing, the active/upper document will be used. With gDocument or 0 the document will be used with which the script was started. |
p = document::page ();
static char* plugin(char* p)
Wich plug-in executes the current cScript?
Name | Type | Default | Description |
Return | String or char* | (Depends on parameter p) Plugin name (XMLLink) | |
p | String or char* | - | Reserved memory for the result |
Get the name of the execting plugin
char p[1024];
showmessage (document::plugin (p));
static int begin_sequence(char* undo_name = 0)
End the undo sequence of the script and start a new sequence. Undo sequences are a sequence of document changes that can be undone with one undo step. Each script is automatically included in an undo sequence (and can therefore be undone with one Undo).
The length of undo sequences is limited by the amount of data required for the single document changes. Therefore, for very long scripts or scripts with many document changes, it may be necessary to end the current sequence and continue with a new sequence. The undo sequence is automatically ended by calling the function again or by the end of the script. At the end of the script the last undo sequence is ended automatically.
Using comet_pdf the call has no effect.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
undo_name | String oder char* | 0 | Name of the sequnces in menue 0 or "" : "Execute Script" |
static int end_sequence()
End the undo sequence of the current script. All further document changes by the script can then only be undone in individual steps.
The statement should be used only in cases where you certainly do not need an Undo of the document changes of the script. Then, however, it can significantly speed up the processing. In the normal case you should use document::begin_sequence instead which also ends the current undo sequence - but starts a new sequence at the same time.
Using comet_pdf and in Front Row actions the call has no effect.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode |
static int open_sequence(char* name = 0)
DEPRECATED! Please use the function document::begin_sequence instead.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode |
static int purge_sequence()
DEPRECATED! Please use the function document::begin_sequence instead.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode |
static int close_sequence(int seqID, int state = 1)
DEPRECATED! Please use the function document::begin_sequence instead.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode |
static int load(
DBC dbc,
char* attribute,
char* table_,
int ID,
char* creationPath,
float scale = -1.0,
int left = 0,
int top = 0,
int right = 0,
int bottom = 0,
int appendToRecent = 1)
Create and open a document from a database template. The generated ItemRef must be deleted again from the script. Dokuments can be stored in the database with store_macro.
Name | Type | Default | Description |
Return | ItemRef | Reference to the newly created documented, with item::release to delete!! | |
dbc | DBC | - | Database connectio (ODBC or OCI) 0 : current database connection |
attribute | String or char* | - | Attribute name of the database table in which the template is stored |
table_ | String or char* | - | Name of the database table in which the template is stored |
ID | int | - | ID under which the template is stored in the database |
creationPath | String or char* | - | Path for the created file |
scale | float | 1.0 | Current scale |
left | int | 0 | Window position |
top | int | 0 | Window position |
right | int | 0 | Window position |
bottom | int | 0 | Window position |
appendToRecent | int | 1 | Insert the file to the Recent documents menu? 0 : No 1 : Yes |
docRef = document::load (attribute, table_, ID, creationPath [, scale, [, left, top, right, bottom]]);
static int repaint()
Update the presentation of the complete document. The call forces the redrawing of the document window. To render a text again, please use textmodel::force_redraw.
The function has no effect using comet_pdf.
static int set_startpage(
int startpage,
int style = 0,
ItemRef docRef = 0)
Set the start page of a document. Apart from the start page the numbering format (numbers, Roman numerals, letters) can also be specified.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
startpage | int | - | Start page number |
style | int | 0 | Numbering format 0 : 1, 2, 3, 4, ... 1 : I, II, III, IV, ... 2 : i, ii, iii, iv, ... 3 : A, B, C, D, ... 4 : a, b, c, d, ... |
docRef | ItemRef | 0 | The document. If the parameter is missing, the front document is used. With gDocument or 0 the document will be used with which the script was started. |
err_code = document::set_startpage (i, 2);
static int store_macro(
DBC dbc,
char* attribute,
char* table_,
int ID,
char* preview = "",
int preview_size = 200,
char* leftPos = 0,
char* topPos = 0,
char* rightPos = 0,
char* bottomPos = 0,
int formatID = 1)
Save the current frame selection to the database. The target attribute must be a blob. If the attribute name preview is not empty, a preview of the stored selection will be stored there.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
dbc | DBC | - | target database |
attribute | String or char* | - | Attribute name of the database table in which the template is to be stored |
table_ | String or char* | - | Name of the database table in which the template is to be stored |
ID | int | - | ID under which the template is stored in the database |
preview | String or char* | '' | != "" -> Write a preview in the specific attribute |
preview_size | int | 200 | Size of the preview in pixels |
leftPos | String or char* | "" | != "" : Calculate the frames bounding box and write the left position to ths database attribute |
topPos | String or char* | "" | != "" : Calculate the frames bounding box and write the top position to ths database attribute |
rightPos | String or char* | "" | != "" : Calculate the frames bounding box and write the right position to ths database attribute |
bottomPos | String or char* | "" | != "" : Calculate the frames bounding box and write the bottom position to ths database attribute |
formatID | int | 1 | Format of template 1: Classic (InDesign® document) 2: Snippet (InDesign® document) 3: IDML (CS4, not supported for now) |
err_code = document::store_macro (dbc, attr, table_, id [, preview [, preview_size]]);
static ItemList insert_macro(
DBC dbc,
char* attribute,
char* table_,
int ID,
float x = -1000.0,
float y = -1000.0,
int page = -1,
char* layer = 0,
int id1 = 0,
int id2 = 0,
int id3 = 0,
char* stringid = 0,
int autoLoad = 0,
int classID = 0)
Define a database-stored template within the current document. It is recommended that the general function document::place_items is used to insert the templates.
If you call the function from inside a load placeholder, you should take care to import the frames only once. You may use frame::remove_sub_cometgroups if the placeholder makes only one import.
When inserting a template the Template-ID script of this template can decide to use another template instead. For more information see Description of panel 'Templates' and und TemplateID script.
Name | Type | Default | Description |
Return | ItemList | Inserted frames must be deleted again with itemlist::release | |
dbc | DBC | - | Database in which teh template is stored 0 : Use the curent data base |
attribute | String or char* | - | Attribute name of the database table in which the template is stored If attribute and table are empty, the default source for templates is used, you have to give only the template ID. |
table_ | String or char* | - | Name of the database table in which the template is stored If attribute and table are empty, the default source for templates is used, you have to give only the template ID. |
ID | int | - | ID under which the template is stored in the database |
x | float | Original position | Page relative position in points |
y | float | Original position | Page relative position in points |
page | int | Original page | Page number on which the template is to be located |
layer | String or char* | Current layer | Target layer on which the template is to be placed |
id1, id2, id3, stringid | int, int, int, char* | 0, 0, 0, "" | Product ID of the object linked against the template (used also for the Template-ID script, if any script is defined inside the given template). If id1 is 0, linking against the new object is suppressed. |
autoLoad | int | 0 | Link, load and build placeholders of the inserted frames automatically. 0 : No, do not link nor load placeholders 1 : Yes, link, load and rebuild (if nesseccary) all inserted frames. Suppressed, if id1 = 0! -1 : since v3.3.1 R5125 Only link but not load placeholders. Suppressed, if id1 = 0! |
classID | int | 0 | Do only deal with placeholders of the given class ID 0 : Ignore class ID. Link, load and build all placeholders othwise : Do only link, load and build placeholders with the given class id. |
items = document::insert_macro (dbc, attr, table_, id [, x, y [, page [, layer]]]);
static ItemList place_items(
DataPool pool,
char* attribute,
char* table_,
int ID,
float x = -1000.0,
float y = -1000.0,
int page = -1,
char* layer = "",
int id1 = 0,
int id2 = 0,
int id3 = 0,
char* stringid = 0,
int autoLoad = 0,
int classID = 0,
int addToCometGroup = 1)
Insert a template saved in the database or in a file into the current document. If the template is saved as a file the file must be located in the pool data folder (datapool::get_files) in the subfolder table_/attribute under the name ID.indd.
If you call the function from inside a load placeholder, you should take care to import the frames only once. You may use frame::remove_sub_cometgroups if the placeholder makes only one import.
To import frames from an InDesign® document or snippet not coming from the current data pool use the function place_indesign..
The return value of the function is a new allocated itemlist (the list of imported frames). This list will released on the end of the script automatically. But looped calls to the function may allocate a lot of memory if you do not release the result list as soon as possible. So, best practice is : release the result list!
When inserting a template the Template-ID script of this template can decide to use another template instead. For more information see Description of panel 'Templates'.
Name | Type | Default | Description |
Return | ItemList | Inserted frames must be deleted again with itemlist::release | |
pool | DataPool | - | Datapool in which teh template is stored 0 : Use the current datapool |
attribute | String oder char* | - | Attribute name of the database table in which the template is stored If attribute and table are empty, the default source for templates is used, you have to give only the template ID. |
table_ | String oder char* | - | Name of the database table in which the template is stored If attribute and table are empty, the default source for templates is used, you have to give only the template ID. |
ID | int | - | ID under which the template is stored in the database |
x | float | - | Page relative position in points |
y | float | - | Page relative position in points |
page | int | - | Page number on which the template is to be located -1 : Current page |
layer | String oder char* | - | Target layer on which the template is to be placed 0 or "" : deepest layer Using InDesign® Server or comet_pdf the current front page is undefined! |
id1, id2, id3, stringid | int, int, int, String oder char* | 0, 0, 0, "" | Product Id of the object, linked against the template (used also for the Template-ID script, if any script is defined inside the given template). If id1 is 0, linking against the new object is suppressed. |
autoLoad | int | 0 | Link, load and build placeholders of the inserted frames automatically. 0 : No 1 : Yes, load and rebuild (if nesseccary) all inserted placeholders. Suppressed, if id1 = 0! |
classID | int | 0 | Do only deal with placeholders of the given class ID 0 : Ignore class ID. Link, load and build all placeholders othwise : Do only link, load and build placeholders with the given class id. |
addToCometGroup | int | 1 | since Comet3.1 All frames of the template are grouped in one Comet group. make this group a sub groub of the current script frame. 1 : Yes 0 : No. |
Add all entries of level two of selected product to the document. The entries must have their grid and element defined.
#include "internal/text.h" #include "internal/products.h"
int main () { ProductList pl = productlist::get ("selected [level = 2]"); ItemList inserted = 0; int lastElem = 0; int grid, elem, pid; Product p; float left, top; int pnum = page::get (0); char pname[1024]; int cc = 0; float ml, mt, mr, mb;
wlog ("", "# Starting import\n"); progress::start ("Produktaufbau", productlist::length (pl)); page::get_margins (pnum, &ml, &mt, &mr, &mb);
for (p = productlist::first (pl); p; p = productlist::next (pl)) { sprintf (pname, "Product %d [%s]", ++cc, product::gets (p, kStringID)); wlog ("", "# ---> Importing %s\n", pname); progress::step (pname, 1);
pid = product::get (p, kPageitemid); grid = product::get (p, kGridid); elem = product::get (p, kElementid);
if (grid <= 0) grid = 2;
//New page for each block of entries if (lastElem > elem) { page::create (1, pnum+1); pnum += 1; } lastElem = elem;
left = grid::left (grid, elem); top = grid::top (grid, elem);
inserted = document::place_items ( 0, "", "", product::get (p, kPageitemid), left + ml, top + mt, pnum, "", product::get (p, kID), product::get (p, kID2), product::get (p, kID3), product::gets (p, kStringID), 1);
if (inserted) itemlist::release (inserted); inserted = 0; }
progress::stop (); return 0; }
static ItemList place_snippet(
int ID,
float x = -1000.0,
float y = -1000.0,
int page = -1,
char* layer = "",
int id1 = 0,
int id2 = 0,
int id3 = 0,
char* stringid = 0)
Insert a snippet into the current document.
The return value of the function is a new allocated itemlist (the list of imported frames). This list will released on the end of the script automatically. But looped calls to the function may allocate a lot of memory if you do not release the result list as soon as possible. So, best practice is : release the result list!
Name | Type | Default | Description |
ID | int | - | Template ID, this parameter is reserved for future extensions of the snippet functionality and is currently unused |
x | float | - | Page relative position in points |
y | float | - | Page relative position in points |
page | int | - | Page number on which the snippet is to be located -1 : Current page |
layer | String oder char* | - | Target layer on which the template is to be placed 0 or "" : deepest layer Using InDesign® Server or comet_pdf the current front page is undefined! |
id1 | int | - | Id of the snippet to be inserted |
id2, id3, stringid | int, int, String oder char* | 0, 0, "" | Further object Ids. These parameters aure currently unused. |
static ItemList place_indesign(
char* path,
int srcPage,
char* srcLayers,
int cometGroup,
int page,
float x,
float y,
char* layer = "",
int id1 = 0,
int id2 = 0,
int id3 = 0,
char* stringid = 0,
int autoLoad = 0,
int classID = 0,
int addToCometGroup = 1)
Import frames from a InDesign® document or snippet (inds or idml).
The return value of the function is a newly allocated itemlist (the list of imported frames). This list will be automatically be released at the end of the script. But looped calls to the function may allocate a lot of memory if you do not release the result list as soon as possible. So, best practice is : release the result list!
If you call the function from inside a load placeholder, you should take care to import the frames only once. You may use frame::remove_sub_cometgroups if the placeholder makes only one import.
Name | Type | Default | Description |
Return | ItemList | Inserted frames must be deleted again with itemlist::release | |
path | String or char* | - | Complete path to the document or snippet |
⇨ Frames to import. Snippets will ignore these parameters, snippets are always imported completely. | |||
srcPage | int | - | Page number in document (1-based) 0 : Ignore page number and layer and use cometGroup |
srcLayers | String or char* | - | Blank delimited list of layers ("\"AAA\" \"BBB\"") : Import only frames from these layers. "" : Visible layers only |
cometGroup | int | - | Import a comet group. Ignored if page is greater 0 0 : Ignore Comet groupt |
⇨ Import destination | |||
page | int | - | destination page (1-based) |
x | float | - | Page relative position in points -1000.0 : X position of original frame(s) |
y | float | - | Page relative position in points -1000.0 : Y position of original frame(s) |
layer | String or char* | "" | Target layer on which the template is to be placed "" : Current layer |
⇨ Comet things | |||
id1, id2, id3, stringid | int, int, int, String or char* | 0, 0, 0, "" | Product Id of the object linked against the template (used also for the Template-ID script, if any script is defined inside the given template). If id1 is 0, linking against the new object is suppressed. |
autoLoad | int | 0 | Link, load and build placeholders of the inserted frames automatically. 0 : No 1 : Yes, load and rebuild (if nesseccary) all inserted frames. Suppressed, if id1 = 0! |
classID | int | 0 | Do only deal with placeholders of the given class ID 0 : Ignore class ID. Link, load and build all placeholders othwise : Do only link, load and build placeholders with the given class id. |
addToCometGroup | int | 1 | since Comet3.1 All frames of the template are grouped in one Comet group. Make this group a sub groub of the current script frame. 1 : Yes 0 : No. |
Import all frames from Layer 1 and 2 iof page 3.
int main () { document::place_indesign ( "$DESKTOP/aaa.indd", 3, "\"Ebene 1\" \"Ebene 2\"", 0, 4, 100.0, 100.0); return 0; }
Import all frames of the Comet group of a given product. To get the Comet group, the document must be opened and in th foreground. If the frame already imported frames, this frames will removed automatically before importing.
char stSrcDoc [] = "$DESKTOP/big.indd";
int main () { ItemRef docRef = document::get_front (); ItemRef docRef2 = item::alloc (); int mustClose = 0; ItemRef frameRef = item::alloc (); int groupID = 0;
if (!document::is_opened (stSrcDoc, docRef2)) { item::release (docRef2); docRef2 = document::open (stSrcDoc); mustClose = 1; } document::select (docRef2);
document::find_frame (frameRef, 3, 100, 10, 0); if (item::defined (frameRef)) { groupID = frame::get_cometgroup (frameRef, 0); } if (groupID == 0) { if (mustClose) document::close (docRef2); showmessage ("Product not found!"); return 0; }
document::select (docRef); frame::remove_sub_cometgroups (gFrame); document::place_indesign ( stSrcDoc, 0, "", groupID, 2, 100.0, 100.0);
if (mustClose) document::close (docRef2);
return 0; }
static int find_frame(
ItemRef frameRef,
int classid,
int id,
int id2,
int id3,
char* sid = "",
int diveInto = 0)
Find the first frame which is linked with an object of a required class. For the result an ItemRef with reserved memory must be passed.
Name | Type | Default | Description |
frameRef | ItemRef | - | The variable contains the frame after the search, test with item::defined |
classid | int | - | class ID no or 0 |
id | int | - | Look for this product |
id2 | int | - | Look for this product |
id3 | int | - | Look for this product |
sid | String or char* | "" | StringID to search for. A product is only found when all 3 IDs and the StringID match. If no StringIDs are used, an empty value is used. |
diveInto | int | 0 | Search inside sub frames? 0 : no 1 : yes |
Find the first frame which is linked with the shrub (1, 3, 4)
ItemRef frame = item::alloc ();
document::find_frame (frame, 1, 1, 3, 4); if (!item::defined (frame)) { item::release (frame); showmessage ("frame not found"); return 1; }
static int export_(
ItemRef docRef,
char* destPath,
char* format,
char* profile = "",
int uiflag = 0,
int fileflag = 1,
...)
Export a document in a specific target format.
Name | Type | Default | Description | ||||||||||||||||||||||||||||||||||||
Return | int | 0 or ErrorCode 2201 : Document to pack not found 2202 : Error while creating package file 2203 : Cannot open file to package 2204 : Error while checking links of document (NOT missing images!) 2205 : Cannot create internal link object 2206 : Link resource not found 2207 : Error while duplicating image file 2208 : Error while updating link |
|||||||||||||||||||||||||||||||||||||
docRef | ItemRef | - | Document which is to be exported 0 : Document of the active window |
||||||||||||||||||||||||||||||||||||
destPath | String or char* | - | Target path for the export. If the folder path does not exist, it will be automatically generated. | ||||||||||||||||||||||||||||||||||||
format | String or char* | - | Target format. following case sensitiven specifications are possible:
|
||||||||||||||||||||||||||||||||||||
profile | String or char* | "" | Name of the configuration which is to be used for the export.Profile will only be
used for the format "pdf" only: interactive#[key:values;] : Interactive PDF with settings defined in the list of the Key-Value pairs not empty : PDF (print) with the given profile "" or 0 : PDF (Print) with the current PDF export options for PDF (Print) |
||||||||||||||||||||||||||||||||||||
uiflag | int | 0 | 0 : Suppress all dialogs and progess bars. Necessary export specifications are taken from the current or standard specifications of InDesign®
or from the profile. 1 : Only the requisite dialogs will be displayed. 2 : All dialogs and progress bars will be displayed. 3 : with format "package" only Execute the menu command File -> Package .... For technical reasons, this function can only be executed at the next idle time of InDesign® but not directly when called in the script. Before using the function it is essential to check if this is possible and useful in your work flow! |
||||||||||||||||||||||||||||||||||||
fileflag | int | 1 | Should the target file be overwritten? 0 : Do not overwrite the target file 1 : Target file may be overwritten 2 : only for format "package" Compress package folder to zip. If the package folder was created here, it is removed automatically again. (On the Mac, the folder is moved to the trash.) |
||||||||||||||||||||||||||||||||||||
⇨ Additional parameters (any number of key|value(s) pairs in any order). since v3.3 R2580 25.07.2011 and CS4 SWF-Export. Missing values are taken (if available) from the SWF export dialog. The dialog settings are left untouched by calls to document::export (.., "swf", ...). SWF export is no longer supported from InDesign® 2020 onwards! since v4.0.4 R9030, 2. Oct. 2015 You may use the following pkg: options to configure packages (format "package"). |
|||||||||||||||||||||||||||||||||||||||
"swf:generateHTML" | int | - | 0 | 1 | ||||||||||||||||||||||||||||||||||||
"swf:viewAfterExport" | int | - | 0 | 1 | ||||||||||||||||||||||||||||||||||||
"swf:sizeAndFitting:fitTo" | int | - | 0: 1280x800 1 : 1240x620 2 : 1024x768 3 : 984x588 4 : 800x600 5 : 760x420 6 : 640x480 7 : 600x300 |
||||||||||||||||||||||||||||||||||||
"swf:sizeAndFitting:scale" | float | - | 0.0 -100.0 | ||||||||||||||||||||||||||||||||||||
"swf:sizeAndFitting:size" | float, float | - | Size in points | ||||||||||||||||||||||||||||||||||||
"swf:bkTransparent" | int | - | since CS5 0 | 1 |
||||||||||||||||||||||||||||||||||||
"swf:transparencyHandler" | int | - | since CS5 0: ignore 1 : flatten 2 : native |
||||||||||||||||||||||||||||||||||||
"swf:mediaHandler" | int | - | since CS5 0: Include All 1 : Appearance Only |
||||||||||||||||||||||||||||||||||||
"swf:pageTransition" | int | - | 0 : Without since CS5 1 : From document 2 : Blinds 3 : Box 4 : Combine 5 : Cover 6 : Dissolve 7 : Fade 8 : Page Turn 9 : Push 10 : Split 11 : Uncover 12 : Wipe 13 : Zoom In 14 : Zoom Out versions prior CS5 All other values turning on page transitions |
||||||||||||||||||||||||||||||||||||
"swf:bookControl:curl" | int | - | 0 | 1 - Interaktives Aufrollen der Seiten einschliessen | ||||||||||||||||||||||||||||||||||||
"swf:bookControl:showAtRest" | int | - | 0 | 1 | ||||||||||||||||||||||||||||||||||||
"swf:bookControl:cornerTease" | int | - | 0 | 1 | ||||||||||||||||||||||||||||||||||||
"swf:bookControl:sizePercent" | float | - | 0.0 - 100.0 | ||||||||||||||||||||||||||||||||||||
"swf:frameRate" | int | - | since CS5 frames per second |
||||||||||||||||||||||||||||||||||||
"swf:textExport" | int | - | 0 : Live text 1 : Rasterize 2 : Vectorize 3 : Vellum |
||||||||||||||||||||||||||||||||||||
"swf:rasterizePage" | int | - | 0 | 1 | ||||||||||||||||||||||||||||||||||||
"swf:rasterCompression" | int | - | 0 : JPEG 1 : PNG 2 : Automatic |
||||||||||||||||||||||||||||||||||||
"swf:jpgQuality" | int | - | 0 : Minimum 1 : Low 2 : Medium 3 : High 5 : Maximum |
||||||||||||||||||||||||||||||||||||
"swf:rasterResolution" | int | - | resolution (ppi) | ||||||||||||||||||||||||||||||||||||
"swf:curveQuality" | int | - | |||||||||||||||||||||||||||||||||||||
"swf:resampling" | int | - | 0 : off 1 : Average 2 : Subsample 3 : Bikubic |
||||||||||||||||||||||||||||||||||||
"swf:resampleTreshold" | int | - | |||||||||||||||||||||||||||||||||||||
"swf:readerSpreads" | int | - | 0 | 1 | ||||||||||||||||||||||||||||||||||||
"swf:useNetwork" | int | - | 0 | 1 | ||||||||||||||||||||||||||||||||||||
"swf:includePreloader" | int | - | since CS5 0 | 1 |
||||||||||||||||||||||||||||||||||||
"pkg:fonts" | int | 1 | Export fonts? 0 : No 1 : Yes |
||||||||||||||||||||||||||||||||||||
"pkg:images" | int | 1 | Export images? 0 : No 1 : Yes. In this case, all references inside the package are updated too. Missing images do NOT lead errors. Links to missing images are left untouched and a log message is written. |
||||||||||||||||||||||||||||||||||||
"pkg:profiles" | int | 1 | Export color profiles? 0 : No 1 : Yes |
||||||||||||||||||||||||||||||||||||
"pkg:hiddenLayers" | int | 1 | Export colors and fonts from hidden layers? 0 : No 1 : Yes |
||||||||||||||||||||||||||||||||||||
"pkg:ignoreErrors" | int | 1 | Ignore preflight errors? 0 : No 1 : Yes |
||||||||||||||||||||||||||||||||||||
"pkg:report" | int | 1 | Write a report? 0 : No 1 : Yes |
||||||||||||||||||||||||||||||||||||
"pkg:idml" | int | 0 | Available since InDesign® CC, ignored in prio versions. Add an IDML of the document to the package? > 0 : No 1 : Yes |
||||||||||||||||||||||||||||||||||||
"pkg:pdf" | int | 0 | Available since InDesign® CC, ignored in prio versions. Add PDF of the document to the package? > 0 : No 1 : Yes |
||||||||||||||||||||||||||||||||||||
"pkg:pdfstyle" | String or char* | 0 | Available since InDesign® CC, ignored in prior versions. Style for creating the PDF. Take care, it's a String! |
Export the current document in a PDF file. The profile 'Paul' must be set up (Menu; file:PDF-Export specifications:Define ...).
int main () { int result = 0;
result = document::export_ ( 0, "/AAA/BBB/a.pdf", "pdf", "Paul", 0, 1); return 0; }
Make a zip package from the current document. Do not export color profiles and do not write a report.
result = document::export_ (0, "", "package", "", 0, 2, "pkg:profiles", 0, "pkg:report", 0);
static int pdf_export(
ItemRef docRef,
char* destPath,
char* profile = "",
int scope = 2,
List indexes = 0,
...)
PDF export of document pages or spreads in any order.
Since v4.1 R23334 The function can export all Comet notes into the created PDF. To do so, simply add 4 (for visible notes) or 8 (for visible and hidden notes) to the parameter scope of of the function. Please note the installations hints for the support of PDF comments.
This function can also be used to create interactive PDFs. Since it is not possible to store profiles for interactive PDFs, the export options can be made in the script call. To create interactive PDFs, define the profile parameter as follows
interactive#{key:value;} with key and value according to the following table.
If the list of key-values is empty, the current InDesign® settings are used to export interactive PDFs. If at least one value is defined, the values specified in the table in bold type are used as defaults.
Key | Value | Description | |
General | singlePages |
no | 0 yes | 1 |
Pages : Generate separate PDF Files Available since InDesign® 2020 |
singlePagesSuffix | beliebiger String |
Pages : Generate separate PDF Files Suffix Only when creating separate pages (singlePages:yes;) vailable since InDesign® 2020 |
|
magnification | actual fitPage fitWidth fitHeight fitVisible 25 50 75 100 | Viewing : View | |
pageLayout | single singleContinue twoUp twoUpContinue twoUpCover twoUpCoverContinue | Viewing : Layout | |
fullScreen |
no | 0 yes | 1 |
Viewing : Open in Full Screen Mode | |
flipPages |
no | 0 yes | 1 |
Viewing : Flip Pages The specification is used only in full screen mode (fullScreen:yes;). |
|
flipSpeed | Seconds as integer, Default 5 |
Viewing : Flip Pages Every ... seconds The specification is used only in full screen mode (fullScreen:yes;). |
|
transition |
nothing blend combine box cover push uncover wipe zoomIn zoomOut disolve fade turn split |
Viewing : Page Transition The specification is used only in full screen mode (fullScreen:yes;). |
|
autoShow |
no | 0 yes | 1 |
Viewing : View After Exporting | |
showInteractives |
no | 0 - Appearance Only yes | 1 - Include All |
Options : Forms and Media/td> | |
thumbnails |
no | 0 yes | 1 |
Options : Embed Page Thumbnails | |
layers |
no | 0 yes | 1 |
Options : Create Acrobat Layers | |
tags |
no | 0 yes | 1 |
Options : Create Tagged PDF | |
tabs |
definition | 0 structure |
Options : Use Structure for Tag Order For tagged PDFs only (tags:yes;) |
|
Compression | compression |
jpeg lossless auto |
Compression |
quality |
min low medium high max |
JPEG Quality | |
resolution |
PPI as integer Minimum 10 Default 72 |
Resolution (ppi) | |
Advanced | title |
document file |
Accessibility Options : Display Title |
language | String |
Accessibility Options : Language For the available languages and their spelling, please refer to popup menu Accessibility Options : Language. |
|
Security | The security settings depend very much on the used PDF viewer. Viewers like Acrobat or Acrobat Pro may not be able to display all the security settings you have made. If the settings are missing, please check first whether you can create settings manually! | ||
password |
String Default: no password |
Document Open Password | |
authorization |
String Default: no password |
Permissions : Permissions Password | |
allowPrint |
no | 0 low yes | 1 |
Permissions : Print Allowed Only active if an authorization password is set (authorization:'pwd';) |
|
allowAssembly |
yes | 1 no | 0 |
Changes Allowed -> Inserting, deleting and rotating pages Only active if an authorization password is set (authorization:'pwd';) |
|
allowFormfill |
yes | 1 no | 0 |
Changes Allowed -> Fill in form fields and signing Only active if an authorization password is set (authorization:'pwd';) |
|
allowNotes |
yes | 1 no | 0 |
Changes Allowed -> Commenting Only active if an authorization password is set (authorization:'pwd';) |
|
allowExtraction |
yes | 1 no | 0 |
Changes Allowed -> Any except extracting pages Only active if an authorization password is set (authorization:'pwd';) |
|
allowCopy |
yes | 1 no | 0 |
Enable copying of text, images and other content Only active if an authorization password is set (authorization:'pwd';) |
|
allowChange |
yes | 1 no | 0 |
Enable text access of screen reader devices Only active if an authorization password is set (authorization:'pwd';) |
|
plainTextForMeta |
yes | 1 no | 0 |
Enable plaintext metadata Only active if an authorization password is set (authorization:'pwd';) |
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document 0 : current script or front document |
destPath | String or char* | - | complete path and name for the destination 0 or "" : use path and name (with extension .pdf) of the document. (not working on new unsaved documents) |
profile | String or char* | "" | Name of PDF export profiles interactive# : Interactive PDF with the current settings of the PDF export for interactive PDFs interactive#[key:values;] : Interactive PDF with settings defined in the list of the Key-Value pairs not empty : PDF (print) with the given profile "" or 0 : PDF (Print) with the current PDF export options for PDF (Print) |
scope | int | 2 | Export pages or spreads? 1 : spreads 2 : pages Export of Comet notes: +4 : Export visible Comet notes only\ +8 : Export all Comet notes See document::notes::set_pdf_prefs for defualt settings. In comet_pdf there is no visibility of notes, therfores always all notes exported here. Never use PDFs with Comet notes as to be the final print version! If the document does not contain Comet notes that need to be exported, the PDF is left unchanged - or, in other words, a recompositions of the document is not needed in this case. Ignored by Illustrator. |
indexes | List | 0 | List of 0-based page or spread numbers. If 0, the following numbers are used.
If no numbers follow, all pages/spreads are exported.
To place PDF comments on their right sides, pages must be complete and in the right order in case of exporting Comet notes. Ignored by Illustrator. |
... | int, ... | - | Any number of 0-based page or spread numbers, only used if indexes is 0.
To place PDF comments on their right sides, pages must be complete and in the right order in case of exporting Comet notes. Ignored by Illustrator. |
int main () { document::pdf_export (0, "$DESKTOP/aaa/aaa_spreads.pdf", "", 1, 0); document::pdf_export (0, "$DESKTOP/aaa/aaa_spread_2_4.pdf", "", 1, 0, 2, 4); document::pdf_export (0, "$DESKTOP/aaa/aaa3.pdf", "", 2, 0, 3); document::pdf_export (0, "$DESKTOP/aaa/aaa1401.pdf", "", 2, 0, 1, 4, 0, 1); document::pdf_export (0, "$DESKTOP/aaa/aaa1702.pdf", "", 2, 0, 1, 7, 0, 2);
return 0; }
static int html_export(
ItemRef docRef = 0,
char* destPath = "",
int target = 1,
ItemRef itemToExport = 0,
...)
HTML export of a document or parts of a document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode -8000 : Export script not found. See InDesign® subfolder Scripts/Export As XHTML -8001 : No objects to export -8002 : Error while exporting -8003 : Linked image not found -8004 : Linked image out of date -8005 : Cannot export embedded images (Image skipped) -8006 : Linked movie not found -8007 : Skipped unsupported movie(s) - only SWF is suppoerted.. |
|
docRef | ItemRef | 0 | Document to export (from) 0 : current script document |
destPath | String or char* | "" | Complete path for html file. Any existing file will be overridden. "" : Use path and name of the document (with extension .html) |
int | target | 1 | What to export? 0 : current selection 1 : complete document 2 : following object (itemToExport) |
itemToExport | ItemRef | 0 | Valid frame or table reference. If given, docRef is ignored |
⇨ Export option. Any number of key/value pairs. Keys are given as strings ("gifPalette" for instance). Values are depending on their keys, see below. | |||
"bulletListPolicy" | int | 0 | 0 : regular unordered list items 1 : convert bullets to text |
"numberedListPolicy" | int | 0 | 0 : regular ordered list items 1 : fixed list items 2 : convert to text |
"imageHandling" | int | 0 | 0 : Copy original 1 : optimized 2 : link with server path |
"serverImgPath" | String or char* | "" | server path $DESKTOP, ... are not replaced here! |
"serverImgExtension" | String or char* | "" | image extension (e.g. ".jpg") |
"imageConversion" | int | -1 | image conversion -1 : use current setting 0 : automatic 1 : JPEG 1 : GIF |
"gifpalette" | int | -1 | Color panel for GIF -1 : use current setting 0 : Flexibel (no dithering) 1 : System (Mac) 2 : Web 3 : System (Windows) |
"gifInterlaced" | int | -1 | Interlace? -1 : use current setting 0 : no 1 : yes |
"jpegQuality" | int | -1 | image quality -1 : use current setting 0 : low 1 : medium 2 : high 3 : maximal |
"jpegFormat" | int | -1 | format methode for jpeg -1 : use current setting 0 : profgressive encoding 1 : base line |
"styleHandling" | int | 0 | CSS options 0 : empty CCS class declarations 1 : no CSS 2. external CSS file |
"styleSheet" | String or char* | "" | complete path/URL to style file $DESKTOP, ... are not replaced here! |
"linkToJavaScript" | int | 0 | link with external JavaScript file? 0 : no 1 : yes |
"javaScriptURL" | String or char* | "" | complete path/URL to JavaScript file $DESKTOP, ... are not replaced here! |
"showErrors" | int | -1 | Show errors? 0 : no 1 : yes |
Export the complete current document.
int main () { int r;
r = document::html_export (0, "", 1, 0, "showErrors", 1); wlog ("", "#html export : %d\n", r);
return 0; }
Export the current script frame
int main () { int r;
r = document::html_export (0, "", 2, gFrame); wlog ("", "#html export : %d\n", r);
return 0; }
Export of a table.
int main () { int r; Table T = table::alloc ();
table::get (T, 0, 0);
r = document::html_export (0, "", 2, T, "styleHandling", 2, "styleSheet", "/Users/paul/Desktop/xxx.css"); wlog ("", "#html export : %d\n", r);
return 0; }
static int jpeg(
ItemRef docRef,
char* destPath,
char* destName,
int aggregateSpreads,
float resolution,
float bleed,
float greekBelow,
int quality,
int suppressNonPrintableFrames = 0)
Export all spreads or pages to jpeg.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Target document 0 : current document |
destPath | String or char* | - | Destination folder, if an empty string is supplied the document folder will be used |
destName | String or char* | - | Name of JPEG files (without extension). If an empty string is supplied the document name will be used |
aggregateSpreads | int | - | 0: export pages, 1: export spreads |
resolution | float | 72.0 | resolution in dpi |
bleed | float | 0.0 | bleed amount |
greekBelow | float | 7.0 | below which size (in dpi) should text be greeked? |
quality | int | - | Various parameters. Valid settings are: Antialiasing for all objects: kAntiAliasing Full resolution graphics: kFullResGraphics Draw gray: kDrawGray Transparency: kXPOff kXPLow kXPMedium kXPHigh kXPMaximum JPEG Quality (The setting effects only to the quality of the saved file, not of the preview itself!): kJPEGLowQuality kJPEGGoodQuality kJPEGExcellentQuality kJPEGGreatQuality JPEG Encoding (The setting effects only to the quality of the saved file, not of the preview itself!): kJPEGBaseline kJPEGProgressive quality can be supplied as a bitfield (kXXX... + kXXX + ...). The default value is: kAntiAliasing + kFullResGraphics + kXPHigh + kJPEGExcellentQuality + kJPEGBaseline |
suppressNonPrintableFrames | int | 0 | Visibility of non-printable frames 0 Non-printable frames are visible 1 Non-printable frames are NOT in the image |
static int duplicate(
ItemRef docRef,
char* destPath,
int fileflag = 1)
Copy a document in a new file.
Name | Type | Default | Description |
Return | int | 0 oder ErrorCode | |
docRef | ItemRef | - | Document which is to be exported 0 : Document of the active window |
destPath | String or char* | - | Target path for the export. If the folder path does not exist, it will be automatically created. |
fileflag | int | 1 | Should the target file be overwritten? 0 : Do not overwrite the target file 1 : Target file may be overwritten |
static int print(
ItemRef docRef,
char* profile,
char* path = "",
int uiflag = 0,
int fileflag = 1)
Printing a document. The document can optionally be sent to a printer or stored as Postscript file. The specifications of the print settings are defined using the details of the print instructions (Menu; Datei:Druckvorgaben).
Name | Type | Default | Description |
Return | int | 0 oder ErrorCode | |
docRef | ItemRef | - | Document which is to be exported 0 : Document of the active window |
profile | String or char* | - | Print presettings. The specification is case sensitive. See InDesign® menu;
File:Print styles Empty string : use the current settings of the print dialog |
path | String or char* | "" | Empty : print of file query Otherwise : Printer output as Postscript file. The path to the specific file will be created automatically. |
uiflag | int | 0 | 0 : Display all dialogs and progress bars 1 : Do not display progress bars 2 : Warnings are not displayed 4 : Print end-dialog is not displayed 8 : File selection dialog not displayed 0xFF : Nothing displayed The options may be linked with logical OR (|). |
fileflag | int | 1 | Should the target file be overwritten? 0 : Do not overwrite the target file 1 : Target file may be overwritten |
Create a Postscript file from the current file, without displaying any dialogs or progress bars.
document::print (0, "", "/AAA/KKK/GGG/asdd.ps", 0xff);
static int move_pageitems(
ItemRef docRef,
int startPage,
int pages,
int deleteOld = 1,
float leftpages_offset_x = 0.0,
float leftpages_offset_y = 0.0,
float rightpages_offset_x = 0.0,
float rightpages_offset_y = 0.0)
Reposition the contents of document pages. The contents of the pages can then be positioned using a page-specific offset. If not otherwise specified, the contents of the first target page will be deleted.
Name | Type | Default | Description |
Return | int | 0 or error code | |
docRef | Item | - | Target document 0 : Current document otherwise : valid reference to a document |
startPage | int | - | 1-based page number from which the contents are to be
repositioned. 0 : Page of the first selected frame or the current text selection -1 : Currently displayed page of the document |
pages | int | - | Number of pages by which the contents are to be repositioned <0 : Reposition to above 0 : No repositioning to another page >0 : Reposition to below |
deleteOld | int | 1 | Should the contents of the first target page be deleted? 1 : Delete 0 : Do not delete The parameter is only valid for the first page. The following pages are already empty because of the repositioning of their contents. |
leftpages_offset_x | float | 0.0 | If a frame is repositioned from a right or unisex page to a left page , then the frame is repositioned to the left/right on the new page by the specified offset. If the frame was already on the left page, then no offset will be inserted. |
leftpages_offset_y | float | 0.0 | see above, repositioning above or below |
rightpages_offset_x | float | 0.0 | If a frame is repositioned from a left or unisex page to a right page , then the frame is repositioned to the left/right on the new page by the specified offset. If the frame was already on the right page, no offset is inserted. |
rightpages_offset_y | float | 0.0 | see above, reposition below/above |
main () { document::move_pageitems ( 0, // front document 3, // from page 3 ... 2, // two pages back 1, // Last page of doc. before deleting. 11.0, 22.0, 33.0, 44.0); }
static int build_products(
char* statement = "watched",
int flags = 0,
char* errmess = 0,
ItemRef baseFrame = 0,
int removeFrame = 0,
int pageNum = -1,
char* layerName = "",
char* defaultMasterpage = "",
int gridID = 0,
int pageitemID = 0,
int anchor = 0,
float left = 0.0,
float top = 0.0,
float right = 0.0,
float bottom = 0.0,
int purgeSequence = 0,
char* sequName = "",
int preScript = kNoRule)
Product structure. This function is one of the most powerfull of the complete Comet Plugin. All or selected products of the product panel are assumed to the current document. For the positioning all product-specific grid spaces are used. If a product does not have a grid space, a standard grid may be used. The stored specifications of the product are inputted; if these specifications do not exist, a standard specification can be used. During the input care must be taken to ensure that the specifications are not added on top of existing page contents. New pages are automatically set up. The parent page, used for this purpose, can likewise be stored for the product or defined as a standard. Parent page elements are not automatically localised. For the localisation of parent page items on the newly create pages, use the function page::masteritems_load.
The function supports #include "internal/types.h"
Three different algorithms can be used for the import :
Description | New pages | Document customisation | Flags |
grid-orientated Search in the grid for the next free raster space with the following characteristics
|
Each time the last grid space is reached or if the page is full. As the parent page defaultMasterpage is used (or asked prior to import). | Yes. All frames behind the inserted or deleted products are assigned new grid spaces according to the current general positioning information. This feature can be switched off using kDisableOptimizing. | kUseDefaultGrid Optional
|
grid-fixed Use a standard grid. The products will be inserted into the next grid space in each case regardless of the pre-existing document frames. If the positioning info of a product contains a template, this template will be used for importing, otherwise the template defined in pageitemID is used. If even pageitemID is not present, it will be inquired prior to import. |
Each time upon reaching the last grid space. As a parent page defaultMasterpage is used (or inquired prior to the import). | No | kUseDefaultGrid + kIntersectionsAllowed Optional
|
product-defined Use the positioning instructions in the respective products. |
Is always then defined, when the target space is already occupied in the document. It is used in the specified parent pages in the product. If it is not defined, defaultMasterpage is used (or inquired prior to import). | No | kIntersectionsAllowed Optional
|
Prior to building the products, a preparatory script can be executed (Parameter preScript). This script is particular used to post-process the lists of the products to be built. The script is executed after the list of the products to be inserted has been assembled.
The script is defined as are all other scripts in the database table actions or in the XML file actions.xml. It must have the class number 14 (= support script for the product build). For the management of product positionings, pages breaks and ad banners in these scripts see All about "page breaks".
For more details about the scripts see here.Name | Type | Default | Description |
Return | int | 0 or ErrorCode. For an exact error description the function can be assigned an allocated string for the error description, see parameter errmess. | |
statement | String or char* | "watched" | Selection of objects (and sub-objects), which are to be built, see here. |
flags | int | 0 | Import control. The value is given as the sum (byte field) of the following constants; as an example
kUseDefaultGrid + kUseFullPage. There are three different import algorithms, for more see
the table above.
kUseDefaultGrid : Ignore the grid information stored in the products and use the standard grid (see parameter grid). kIgnoreIncompletePlacements : Products with incomplete information on positioning (grie and/or tempate) are not added to the document. kAllowIncompletePlacements : If the product positionings are to be used (kUseDefaultGrid in off status), it is ascertained prior to the import, if all the information is complete. If this byte is defined, incomplete information is authorised and the standard specifications used. kCheckIfNotExists : Check before inserting if the product is already planned within the document, if yes, it will no longer be inserted. kIntersectionsAllowed : When inserting the products with a standard grid a check is made to ensure no pre-existing page contents are overlapped and the the new product also fits the page. The check can be interrupted using the kIntersectionsAllowed flag because then the next empty grid space is automatically used. (s.a. kUseFullPage, kCheckGridElementSize kCheckGridElementSize : From the grid spaces normally only the positions are used. Using the flag a check can additionally be made to see if the new frames also fit into the grid space. Only active if overlapping is not permitted (kIntersectionsAllowed not switched on). kUseFullPage : When testing the pre-existing page contents, a check is also made to see of the new product actually fits the bounding box around all current grid places. With the flag it can be stipulated that the current page including the page margins may be used. Only active if intersections are not permitted (kIntersectionsAllowed not switched on). kUseBleed : like kUseFullPage, but the bleed is added to the page size kPreferDefaultPageItem : Use template pageitemID for all products to insert and ignore the templates given in the products. kShowErrors : Errors that arise are automatically shown in an error dialog. |
errmess | String or char* | 0 | If the variable identifies an allocated string (e.g. of type char[256] or type String), an error message can be received here. |
⇨With the following information the start page and the layer for the import are specified. | |||
baseFrame | ItemRef | 0 | The page and the layer in which the frame is located in the document will be used as the start position for the import. If the information is empty, this information will be ascertained from pageNum and layerName. |
removeFrame | int | 0 | Should the start frame be removed from the document?
0 : No, keep frame otherwise : delete frame |
pageNum | int | -1 | 1-based page number, after which the insert is to be made. The value will only then be
used if baseFrame is = 0. -1 : Use the current page Using InDesign® Server or comet_pdf the current front page is undefined! |
layerName | String or char* | - | Name of the target layer for the import. The value is only then
used, if baseFrame is = 0. 0 or "" : Current layer |
⇨Information on standard grid, template and parent page. The values will only be used if the flag kUseDefaultGrid
is activated or if the flag kAllowIncompletePlacements is activated and a product to be inserted does not have
complete positioning information. Prior to the insert of the product, it is ascertained if at least one product requires the standard value. If yes, a check is made if all standard values have been assumed by the function. If at least one of this values is missing, a dialog is automatically opened, which inquires the missing values. |
|||
defaultMasterpage | String or char* | 0 | Name of the parent page which should be used if new pages must be inserted into the document.
If in one-page documents different parent pages are to be used for left and right pages,
both parent page names are stated within simple quotation marks and divided by a comma
comma. Example 1 : "A parent page" Example 2 : "'A parentpage left', ''A parentpage right'" |
gridID | int | 0 | Standard grid. For inserting, the sequence of the storing positions (sorted according to ID) of the grids will be used. |
pageitemID | int | 0 | Standard template for inserting products. If a product contains information different from that of the template , this template will be used. In doing so it will be ensured that the template fits the target page type and where requireda an alternative template may be selected, for more see Description of the panel 'Templates'. |
anchor | int | 0 | Blocked page areas. The specification is only valid for the start page of the import, all successive pages
are of course newly set up and are empty. For the comparison limits the frame baseFrame is used.
If this information is empty, the limits can be given in the following parameters left, .... -1 : Open dialog for request 0 : Use complete page for inserting 1 : Begin below the frame 2 : Begin alongside the frame 3 : Inserts can be made under and alongside the frame |
⇨Specifications on positioning on the start page. The specifications are only valid for the start page and only for objects that are inserted with the standard grid. It can be determined if inserts may first be made alongside and/or belown the specified frame. In this cases only those grid spaces are selected whose frames does not intersect the specified frame. | |||
left | float | 0.0 | When using the standard grid it must be ascertained which of the grid spaces should first be used. This is determined using a page frame and an anchor position. left determines the left page of the frame. |
top | float | 0.0 | ... top page of the frame |
right | float | 0.0 | ... right page of the frame |
bottom | float | 0.0 | ... bottom page of the frame |
purgeSequence | int | 0 | Process products each in its own sequence 0 - Whole assembly in a sequence. The assembly can be reversed with an undo. For larger imports, the import will frequently be interrupted by a dialog which issues an unhelpful message stating that the sequence is too large, and therefore cannot be reversed. 1 - Every product will be processed in its own purged sequence (see purge_sequence). Using Undo each product will be removed individually from the document. With "clean" the parameter has no meaning. |
sequName | String or char* | "Building %d. Produkt" | Name of the individual import sequence, is only used where purgeSequence != 0. The specification must contain exactly one %d, which is substituted by the current import counter, i.e. "Import %d. Product" for example. If the specification is empty, the default string will be used. |
preScript | int | kNoRule | ID of the preparation script. The script is executed in that the list of the products to be imported is determined
and can then be used to process the product list. For more see product::set, product::clone,
productlist and on chapter Script support. kNoRule - No script is executed Sonst ID des Skriptes, Skriptaufbau siehe hier. |
Assemble in the document using a panel script all products which are eye-marked, which have a higher-layer product.
#include "internal/types.h"
int main () { char errmess[512]; int result;
if (gRun != 1) return 0;
result = document::build_products (   "watched id2 > 0",// Only eye-marked products   kAllowIncompletePlacements,   errmess, // Error report
  // Target page and layer. Is gFrame defined,   // Page numbers and layers will be ignored   gFrame,   true, // Delete frames   -1, // page number   "", // layer
  // Placement notice   // If one of the values is not defined then   // a dialog will be opened, and the value   // is queried.   "A-Musterseite",// Parent page   2, // Grid ID   1, // Template ID   0); // Anchor (undef = -1)
if (result && result != -1199)   showmessage ("%d : %s", result, errmess);
return 0; }
To assemble all products with a higher-layer product, which can be read from the list, only the statement above must be changed.
list id2 > 0 and layer = 1
And to demonstrate how short the instruction can be, here again without commentary.
int main () { char errmess[512]; int result;
if (gRun != 1) return 0;
result = document::build_products (   "watched id2 gt; 0",   kAllowIncompletePlacements,   errmess);
if (result && result != -1199) showmessage ("%d : %s", result, errmess);
return 0; }
static int get_firstpagetype(ItemRef docRef = 0)
Determine if the first document page is a left, middle or right page. The command only returns a result for one-page documents, otherwise a 1 will always be returned.
Name | Type | Default | Description |
Return | int | kLeftPage (0) : left page kRightPage (2) : right page 1 : no or two-page document |
|
docRef | ItemRef | 0 | Dokument, the type of first page of which is to be determined 0 : Current document |
static int set_firstpagetype(int typ, ItemRef docRef = 0)
Define whether the first page of the document is a left or right page. The determination of the first page type only applies to one-page documents. The page type is required in order to determine the page type of a given document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
typ | int | - | kLeftPage (0) : left page kRightPage (2) : right page |
docRef | ItemRef | 0 | Document, where the first page type is to be changed 0 : Current document |
static int split(
ItemRef docRef = 0,
char* postfix = "",
char* basename = "",
char* destPath = "")
Split a document into its pages. Every document contains all parent pages, styles, colors and so on. Left pages stay left pags, rigt pages stay right pages.
Existing page document in the destination folder are overridden!
Name | Type | Default | Description |
Return | int | errro code or 0 | |
docRef | ItemRef | 0 | Source document |
postfix | String or char* | "" | The names of the page documents consists of a postfix and the page number, for instance myfile_1.indd, myfile_2.indd, ... . In this example "_" is the postfix. |
basename | String or char* | "" | Base name of page documents "" : Use name of source document |
destPath | String or char* | "" | Destination folder for the page documents. If the folder doesn't exist, it will cretaed. "" : Folder of source document |
static int concat(char* dest, char* src)
Concatanation of one document to another. All pages of the second document will append to the destinations document. Parent pages, styles, colors and so on are not imported.
Addings pages to a document may change their spread order! Magnets between pages of different spreads are deleted.
Visible Comet note are relinked to their current destinations. Invisible notes are ignored!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
dest | String or char* | - | Full path of document to append on. Doesn't matter, if this file opened already! "" : front document |
src | String or char* | - | Full path of file to append |
static int join(
char* firstPath,
char* newname = "",
char* destpath = "",
long lastPage = -1)
DEPRECATED! Please use the functions file::get_nth and document::concat instead.
Name | Type | Default | Description |
Return | int | -1198 |
static int allow_shuffle(ItemRef docRef = 0, int allow = 1)
Allow or disable page shuffling in a document.
Name | Type | Default | Description |
Return | int | errro code or 0 | |
docRef | ItemRef | 0 | Source document 0 : Use front document |
allow | int | 1 | Allow shuffle on/off
1 : Allow 0 : Disable |
static int justify_text(
ItemRef docRef,
int page,
char layerName,
int keepLast,
char* style1,
...)
Vertical justification.
Name | Type | Default | Description |
Return | int | errro code or 0 | |
docRef | ItemRef | - | Source document 0 : Use front document |
page | int | - | 1-based doc page. Apply the function only to frames on this page -1 : all pages If a text chain contains frames on other pages too, the function is applied to the frames on this pages too! |
layerName | String or char* | - | Apply function on frames on the given layer "" : all layers "--visible--" : visible layers only "--active--" : active layer only otherwise : valid layer name |
keepLast | int | - | 1 : Leave the last frame of a text chain untouched 0 : Can change the last frame too |
style1, percent1, ... | String or char*, float, ... | - | List of paragraph style names and percentages (float).
With the percentage you can determine, how much space is occupied for justification by this style.
The sum of all values may not exceed 100.0 percent. 0 or "" : Wildcard for "any" style |
Here you can find a (german) test document
static int justify_text_reset(
ItemRef docRef,
int page,
char* layerName,
int keepLast,
char* style1,
...)
Reset vertical justification.
Name | Type | Default | Description |
Return | int | errro code or 0 | |
docRef | ItemRef | - | Source document 0 : Use front document |
page | int | - | 1-based doc page. Apply the function only to frames on this page -1 : all pages |
layerName | String or char* | - | Apply function on frames on the given layer "" : all layers "--visible--" : visible layers only "--active--" : active layer only otherwise : valid layer name |
keepLast | int | - | 1 : Leave the last frame of a text chain untouched 0 : Can change the last frame too |
style1, ... | String or char*, ... | - | List of paragraph styles to reset to the style definition |
Here you can find a (german) test document
static int remove_redundant_tags(
ItemRef docRef = 0,
int page = -1,
char* layerName = "")
Clean up textplaceholders. Text attribute changes such as font, textsize, color, ... are breaking the Comet placeholders into several so called runs. The Comet plug ins are runs save. But for templates and document templates it would be a good idea, to remove this redundant information for performance reasons.
Using the application menu Plug Ins:Placeholder:Remove redundant placeholders before save users can remove redundant placeholders automatically.
This function removes all redundant placeholder runs from the document. You're able to shrink the selection to a given page and/or layer, but is recommended to remove redundant runs from the entire document.
Name | Type | Default | Description |
Return | int | errro code or 0 | |
docRef | ItemRef | 0 | Source document 0 : Use front document |
page | int | -1 | 1-based doc page. Apply the function only to frames on this page -1 : all pages |
layerName | String or char* | "" | Apply function on frames on the given layer "" : all layers "--visible--" : visible layers only "--active--" : active layer only otherwise : valid layer name |
static int table_of_content(
ItemRef frameRef,
char* styleName,
int update_all = 1)
Insert or update table(s) of content (TOC). In case an overset in any text of the document, a warning dialog asks if we should include table of content entries in overset. In fact, the include overset flag is set in runtime through user's input(a warning dialog). Currently, the function is only used for scripting to control the default behavior if we should include overset or not.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
frameRef | ItemRef | - | Destination frame != 0 : Insert or update a TOC (in) this frameIf the frame isn't a text frame, it is converted to a text frame. Any existing text in the frame will be deleted. 0 : Update all TOCs of the given name styleName existing inside the front document (set update_all to 1 in this case) |
styleName | String or char* | "" | Name of an existing TOC style "" : Use the documents default TOC style |
update_all | int | 1 | If the document contains some more TOCs of the given style, what do you prefer? 1 : update these TOCs too 0 : leave these TOCs untouched |
Replace the content of the current script frames with the TOC named "My content". TOCs with the same name probably inside the the document are left untouched.
int main () { int res;
res = document::table_of_content (gFrame, "My content", 0); wlog ("", "# table_of_content returns %s\n", serror (res));
return 0; }
static int adapt_many(char* xmlControlFile = 0)
Apply page adaptions for the front document. The destination sizes are give in an XML file. If the given path is empty, a file dialog is invoked. You must have the PageAdapter plug-in installed and licensed to run the function.
Name | Type | Default | Description |
Return | int | errro code or 0 | |
xmlControlFile | String or char* | "" | complete path to the control file "" : file dialog |
The example shows a valid control file. The following formats are defined : A3, A4, A5, B5, CD, US-Letter, US-Long, Tabloid, US-Letter Half, US-Long Half.
<?xml version="1.0" encoding="utf-8"?> <adaptions basename = "" folder = "$DESKTOP/adapt/ok" errfolder = "$DESKTOP/adapt/err"> <adaption> <format>A4</format> <width></width> <height></height> <name></name> </adaption> <adaption> <format>A5</format> <width></width> <height></height> <name></name> </adaption> <adaption> <format>A3</format> <width></width> <height></height> <name></name> </adaption> </adaptions>
static int adapt(
float width,
float height,
char* destPath = 0,
char* destName = 0)
Create one adaption of the current document. You must have the PageAdapter plug-in installed and licensed to run the function.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
width, height | float | - | Size of the new document in points. |
destPath | String or char* | "" | Destination folder "" : Use the current doc path |
destName | String or char* | "" | Name of new doc (without the extender .indd) "" : Use the current doc name plus "_wxh" |
AppleScript to adapt a document
tell application "Adobe InDesign® CS5"
set d to document 1
tell d
adapt width 333.3 height 444.4
end tell
end tell
static int adapt_self(float width, float height)
Create one adoption of the current document. You must have the PageAdapter plug-in installed and licensed to run the function.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
width, height | float | - | Size of the new document in points. |
static int start_stamping(
int actionID,
ItemRef origin,
ItemList designated = 0,
int autoClose = 0)
Starts the 'Stamping' of frames. Stamping is the term used to describe a process that starts from an first frame, the so-called origin and does 'something' to the frames that are subsequently clicked. The stamping action can be arbitrary and can refer to the number of clicked frames and/or to the original frame.
Stamping actions can only be started from the Front Row panel!
Due to an InDesign bug, stamp actions can unfortunately not be undone as one step at the moment. Therefore, to undo the actions, unfortunately, a corresponding number of undos must be made. We will correct this behavior as soon as possible - but this is not up to us alone.
Stamp scripts must be introduced with the following pragma in exactly this notation:
#pragma _stamp_
Stamping is divided into three steps:
Usually, all three steps can be implemented in one script. Based on the existence of global variables (see below) you can use declared to distinguish whether the stamping should be started or executed. In all cases the stamping must be terminated either automatically or with document::stop_stamping function. To finish the stamping the counter gCounter or e.g. the CMD key (system::cmdkey) are suitable.
Stamping can be restricted to any number of frames by the designated list. In this case clicks on other frames will be ignored and stamping can be aborted automatically when the last frame has been processed. To do this, set the autoClose parameter to the value 1.
If a frame list is specified, all involved frames will be marked with a corresponding red sequence number when the stamping process starts. The new sequence numbers assigned when clicking are displayed in blue behind the old numbering.Do show the sequence numbers the Nails and Magnets must be visible (menu Document Context -> Nails and Magnets -> Show). Here is a screenshot:
To correct the already assigned stamp order, simply click in a frame that is already highlighted in blue. The sequence and the counter \span[src]{gCounter will then automatically reste to this frame and all frames with a higher blue number will have their blue number taken away again.
Without or with empty frame list no sequence numbers are shown.
The following global variables are defined when performing the stamp actions in steps 2 and 3 (but not in step 1).
Name; | Type | Description |
gCounter | int* |
0-based counting number of the stamp. The variable is a pointer, So you can change the count number in the script. To get its conent, use *gCounter. |
gOriginalFrame | ItemRef | The first frame of the stamping action passed in in the parameter origin of document::start_stamping. |
Name | Type | Default | Description |
Return | int | 0 : No error and continue 1 : Cancel stamping |
|
actionID | int | - | ID of the action to be performed. -1 : Current script |
origin | ItemRef | - | Original (first) frame. Usually this is the current script frame gFrame. |
designated | ItemList | 0 | List of frames that can be stamped. The list should contain the origin frame.
The frames will have a sequence number circled in red in the order of the list. 0 : All frames may be edited. In this case, the frames do not receive sequence numbers. |
autoClose | int | 0 | Do you want stamping to end automatically? 1 : Yes. Stamping will automatically stop when the gCounter counter reaches the length of the designated list. If the designated list is empty, the option is ignored. Note : By incrementing the counter or with a return value > 0 you can end the stamping stamp independent of this option earlier. otherwise : Do not end automatically |
The script takes the color of the first frame and decreases the amount of green in all subsequent frames by 20.
Here is a before/after screenshot where stamping was started in the green frame and then the blue frames were clicked in sequence.
#pragma _stamp_
#include "internal/types.h" #include "internal/text.h"
int main () { float c1, c2, c3, c4;
if (system::cmdkey ()) { document::stop_stamping (); beep (); return 1; }
if (!declared ("gCounter")) { document::start_stamping (-1, gFrame); return 0; }
if (*gCounter > 0) { frame::get_color (gOriginalFrame, 0, 0, &c1, &c2, &c3, &c4); frame::color_rgb (gFrame, (int)(c1), (int)(c2) - (20 * *gCounter), (int)(c3)); }
return 0; }
The next example is a bit more complex: All frames of the current page (or for left pages all frames of the spread) which contain a certain placeholder (in the example the placeholder 10) are searched. The found frames are sorted page by page by their placeholder prefix (which in this case should contain a number). With this frame list the stamping is started. With every click into a frame of this list the placeholder now gets t he current sequence number (plus 1, because it is 0-based!) as prefix. If the last frame is reached, the stamping is finished automatically.
#pragma _stamp_
/* @@ICONID 533 @@SEQ 1 @@LABEL Leitziffern @@HELP Your Help Text */
#include "internal/types.h" #include "internal/text.h"
//***************************************************************************
int stPlaceholderID = 10;
//***************************************************************************
// Sort all links by their prefixes // int sort_links (Link a, Link b) { int result = 0; int pga = page::get (link::frame (a)); int pgb = page::get (link::frame (b)); String prea = string::alloc (); String preb = string::alloc ();
if (pga == pgb) { link::prefix (a, prea); link::prefix (b, preb); if (string::compare (preb, prea) < 0) result = 1; } else { if (pgb < pga) result = 1; }
string::release (prea); string::release (preb); return result; }
//***************************************************************************
// Get all frames of the page // If we are on a left page, also add the frames of the right page. // ItemList get_frames (ItemRef fr) { int pg = page::get (fr); ItemList pageFrames = itemlist::pageframes (pg, 1); ItemList pageFrames2 = 0; LinkList lli = linklist::alloc (0); Link li; ItemRef lif;
itemlist::sort (pageFrames, kSortRowwise); if (pg % 2 == 0) { pageFrames2 = itemlist::pageframes (pg + 1, 1); itemlist::sort (pageFrames2, kSortRowwise); itemlist::appendlist (pageFrames, pageFrames2); itemlist::release (pageFrames2); }
linklist::collect_any (lli, pageFrames, "--list--", kFirstIgnore, kSortNo, stPlaceholderID); linklist::sort (lli, sort_links); itemlist::clear (pageFrames); li = linklist::first (lli);
while (li) { lif = link::frame (li); if (itemlist::get_pos (pageFrames, lif) < 0) { itemlist::append (pageFrames, lif); } li = linklist::next (lli); } linklist::release (lli);
return pageFrames; }
//***************************************************************************
int find_placeholder (ItemRef fr, int pid) { int result = -1; int pos = 0; int len, phid;
while (pos < textmodel::fulllength (fr)) { len = 0; textmodel::get_placeholder (fr, pos, &pos, &len, &phid); if (len > 0) { if (phid == pid) { result = pos; break; } pos = pos + len; } else { pos = pos + 1; } }
return result; }
//***************************************************************************
// Main function // int main () { char txt [512]; ItemList pageFrames = 0; int pos;
/span[c-comment]{// Emergency exit} if (system::cmdkey ()) { document::stop_stamping (); wlog ("", "# Stamping Finished\n"); beep (); return 1; }
if (!declared ("gCounter")) { pageFrames = get_frames (gFrame); document::start_stamping (-1, gFrame, pageFrames, 1); itemlist::release (pageFrames); wlog ("", "# Start stamping\n"); return 0; }
pos = find_placeholder (gFrame, stPlaceholderID); if (pos < 0) return 0;
sprintf (txt, "%d | ", *gCounter + 1);
placeholder::change_tags (gFrame, 0, "Prefix+Apply", txt, kTextPlaceholder, pos, 1); placeholder::load (gFrame, 0, pos, 1);
return 0; }
static int stop_stamping()
Finish stamping frames.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode |
static int resize(float width, float height)
Resize the current document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
width, height | float | - | new size of the new document in points. |
static int getid(
ItemRef docRef,
int* id1,
int* id2 = 0,
int* id3 = 0,
char* stringid = 0)
Get the Comet id of a document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : aktuelles Dokument (gDocument) |
id1 | int* | - | Variable for the ID1 of the document ID |
id2 | int* | 0 | Variable for the ID2 of the document ID, null allowed |
id3 | int* | 0 | Variable for the ID3 of the document ID, null allowed |
stringid | String or char* | 0 | Variable for the StringID of the document ID, null allowed |
static int setid(
ItemRef docRef,
int id1,
int id2 = 0,
int id3 = 0,
char* stringid = 0)
Set the Comet id of a document. ID1 of a document must not be <0!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : aktuelles Dokument (gDocument) |
id1 | int | - | Value for ID1 of the document ID |
id2 | int | 0 | Value for ID2 of the document ID |
id3 | int | 0 | Value for ID3 of the document ID |
stringid | String or char* | 0 | Value for StringID of the document ID |
static ItemRef get_book(ItemRef docRef = 0)
Get the book of a document. The book must must be opened in InDesign® .
Name | Type | Default | Description |
Return | ItemRef | New allocated reference to the open book. You must release this result before a next call to the function using item::release 0 : No book found or open or no document opened |
|
docRef | ItemRef | 0 | Document to find the book for 0 : front document |
Get the book of the current document and write all siblings of the book to the logfile.
int main () { ItemRef book = document::get_book (0); int i;
if (book::is_valid (book)) { for (i = 0; i < book::count_docs (book); i++) { wlog ("", "%d. document : '%s'\n", i+1, book::nth_doc (book, i)); } }
item::release (book); return 0; }
static int update_crossrefs(
ItemRef docRef = 0,
ItemList frames = 0,
int updateCrossrefs = 1,
int showProgress = 0)
Update all cross reference placeholders of a given document. If the book is part of an opened book, all documents of this book are updated too.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | document to update all cross reference placeholders 0 : current script or front document |
frames | ItemList | 0 | Update only placeholders of the given frames. In this case, the docRef is ignored. |
updateCrossrefs | int | 1 | Updating cross reference placeholders? 0 : No. Only affected, if the given document is part of a book. In this case the book is repaginated only. 1 : Only if the document is part of an opened book. In this case, all documents of the book are updated too. 2 : In single documents too. |
showProgress | int | 0 | Show progress while updating cross reference placeholders? 0 : No 1 : Yes |
static int get_bleed(
ItemRef docRef,
int pageNum,
float* inner,
float* top,
float* outer,
float* bottom,
int* isUniform)
Get current document bleed.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script or front document |
pageNum | int | - | 1- based page number. The page is needed, because the bleed is given for inner and outer edges (not left and right) -2 : Get bleed without page checking -1 : current front page Using InDesign® Server or comet_pdf the current front page is undefined! Ignored by Illustrator. |
inner, top, outer, bottom | float* | - | output variables (All values are given in points.) |
isUniform | int* | - | Use the same bleed for all edges? |
static int get_slug(
ItemRef docRef,
int pageNum,
float* inner,
float* top,
float* outer,
float* bottom,
int* isUniform)
Get current document slug.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script or front document |
pageNum | int | - | 1- based page number. The page is needed, because the bleed is given for inner and outer edges (not left and right) -2 : Get bleed without page checking -1 : current front page Using InDesign® Server or comet_pdf the current front page is undefined! |
inner, top, outer, bottom | float* | - | output variables (All values are given in points.) |
isUniform | int* | - | Use the same slug for all edges? |
static int set_bleed(
ItemRef docRef,
float inner,
float top,
float outer,
float bottom)
Change the document bleed. Changing the bleed of a document will cause InDesign® to change the documents pasteboard size!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script or front document |
inner | float | - | New value for the inner bleed (in points). If top, outer and bottom are missed, this value is used for all the other edges too. |
top, outer, bottom | float | see above |
static int set_slug(
ItemRef docRef,
float inner,
float top,
float outer,
float bottom)
Change the document slug. Changing the slug of a document will cause InDesign® to change the documents pasteboard size!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script or front document |
inner | float | - | New value for the inner slug (in points). If top, outer and bottom are missing, this value is used for all the other edges too. |
top, outer, bottom | float | see above |
static int get_pasteboard(
ItemRef docRef,
float* left,
float* top,
float* right,
int* bottom)
Get the documents pasteboard coordinates.
Valid only for CS3 and CS4. For versions since CS5 please use get_pasteboard_gutter.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode pasteBoardDocErr (1272) : CS versions since CS5 |
|
docRef | ItemRef | - | document 0 : current script or front document |
left, top, right, bottom | float* | - | Pasteboard in points |
static int set_pasteboard(
ItemRef docRef,
float width,
float height)
Set the size of the documents pasteboard. A 200 pixel wider pasteboard will change the left and and right edge of the pasteboard by 100 points.
The paste board size is limited by exsiting frames automatically. Since CS5 at least one side of frames remains visible. In versions prior CS5 the whole frame remains visible.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode pasteBoardDocErr (1272) : CS versions since CS5 |
|
docRef | ItemRef | - | document 0 : current script or front document |
width, height | float | - | new pasteboard size in points |
static int get_pasteboard_size(
ItemRef docRef,
int pageNum,
float* left,
float* top,
float* right,
float* bottom)
Get the documents pasteboard coordinates. The functions supports the CS5 feature of different page sizes.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script or front document |
pageNum | int | - | 1-based page index Ignored in versions prior CS5. Since CS5 : Calculate the paste bord of the spread containing the given page. |
left, top, right, bottom | float* | - | Pasteboard in points |
static int set_pasteboard_size(
ItemRef docRef,
int pageNum,
float width,
float height)
Set the size of the documents pasteboard.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script or front document |
pageNum | int | - | 1-based page index Ignored in versions prior CS5. Since an InDesign® bug in CS5 you have to fill it with the index of an existing page. |
width, height | float | - | new pasteboard size in points |
static int get_pasteboard_gutter(
ItemRef docRef,
float* minXBorder,
float* minYBorder)
Get the documents pasteboard borders.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode pasteBoardDocErr (1272) : CS versions prior CS5 |
|
docRef | ItemRef | - | document 0 : current script or front document |
minXBorder | float* | - | return the minimum value for left and right border. |
minYBorder | float* | - | return the minimum value for top and bottom border. |
static int set_pasteboard_gutter(
ItemRef docRef,
float minXBorder,
float minYBorder)
Set the documents pasteboard borders.
The paste board size is limited by exsiting frames automatically. At least on boarder of a frame remains visible.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode pasteBoardDocErr (1272) : CS versions prior CS5 |
|
docRef | ItemRef | - | document 0 : current script or front document |
minXBorder | float | - | new minimum value for left and right border. -1.0 : Do not change -10.0 : Default (595.276 Pt, InDesign® preferences for this value are ignored.) |
minYBorder | float | - | new minimum value for top and bottom border. -1.0 : Do not change -10.0 : Default (72.0 Pt, InDesign® preferences for this value are ignored.) |
static int show_page_elements(ItemRef docRef, int state)
Show or hide the page elements linked with any document page.
Page elements are never shown in prints nor PDFs. Changes made by this function are only visible in InDesign® Desktop, but still committed to the document by InDesign® Server and comet_pdf aswell. With comet_pdf you can export page elements to PDFs using the option -ae.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Valid document reference 0 : current document |
state | int | -1 | State -1 : Toggle 0 : Hide 1 : Show |
static int page_elements_shown(ItemRef docRef)
Are Page elements currently shown in the document?
Name | Type | Default | Description |
Return | int | 0 : invisible (or error) 1 : visible |
|
docRef | ItemRef | 0 | Valid document reference 0 : current document |
static int export_notes(
ItemRef docRef = 0,
char* destPath = 0,
String destString = 0,
int flags = 4)
static int import_notes(
ItemRef docRef = 0,
char* srcPath = 0,
String srcString = 0,
int flags = 6)
static int show_notes(ItemRef docRef = 0)
static int hide_notes(ItemRef docRef = 0)
static int set_default_style(
ItemRef docRef,
int type,
char* stylePath)
Set the current default paragraph or text style. Styles are set document dependent.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document 0 : current document |
docRef | ItemRef | - | Document 0 : current document |
type | int | - | type of style? 1 : paragraph style 2 : text style |
stylePath | String or char* | - | Name (or ':' delimited path) of style to use as the new documents default |
Get the current default paragraph style and then set a new one.
int main () { char oldStyle [256]; int res;
*oldStyle = 0; document::get_default_style (0, 1, oldStyle); showmessage ("Old default style : '%s'.", oldStyle);
res = document::set_default_style (0, 1, "Beta:Geuze"); if (res) showmessage ("Cannot set default style.");
return 0; }
static char* get_default_style(
ItemRef docRef,
int type,
char* stylePath)
Get the current default paragraph or text style. Styles are set document dependent.
Name | Type | Default | Description |
Return | String or char* | (Depends on parameter stylePath) A pointer to stylePath | |
docRef | ItemRef | - | Document 0 : current document |
type | int | - | type of style? 1 : paragraph style 2 : text style |
stylePath | String or char* | - | Name of style (or complete, ':' delimited style path) |
Get the current default style and change it.
int main () { char oldStyle [256]; int res;
*oldStyle = 0; document::get_default_style (0, 1, oldStyle); showmessage ("Old default style : '%s'.", oldStyle);
res = document::set_default_style (0, 1, "Beta:Geuze"); if (res) showmessage ("Cannot set default style.");
return 0; }
static int set_modified(ItemRef docRef = 0, int modified = 0)
Set the modified-state of a document. The function does not change the document itself.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Document 0 : current document |
modified | int | 0 | state of the document 0 : document not modified 1 : document modified |
Suppress saving a possible changed document. int main () { document::set_modified (); return 0; }
static int get_modified(ItemRef docRef = 0)
Get the modified-state of a document.
Name | Type | Default | Description |
Return | int | 0 (not modified), 1 (modified) or ErrorCode | |
docRef | ItemRef | 0 | Document 0 : current document |
Exclude unsaved documents from processing
int main ()
{
if (document::get_modified ())
{
return 0;
}
// further processing
// ...
return 0;
}
static int set_units(
ItemRef docRef = 0,
int horiz_unit = 0,
int vert_unit = 0,
int text_units = 0,
int text_size_units = 0,
int print_units = 0,
int line_units = 0,
float customHPoints = -1.0,
float customVPoints = -1.0,
float key_nudge = -1.0,
float ppi = -1.0)
Set document measurement units.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document 0 : current document |
horiz_unit, horiz_unit | int | 0 | horizontal/verctical unit 0, kUnitUndefined: leave unchanged kUnitPoints kUnitPicas kUnitInches kUnitInchesDecimal kUnitMillimeters kUnitCentimeters kUnitCentimeters kUnitCiceros kUnitAgates (ab CS5) kUnitPixels (ab CS5) |
text_units | int | 0 | Units for (??) 0, kUnitUndefined: leave unchanged kUnitPoints kUnitPixels (ab CS5) |
text_size_units | int | 0 | Units for text size 0, kUnitUndefined: leave unchanged kUnitPoints kUnitPixels (ab CS5) |
print_units | int | 0 | Units for printing 0, kUnitUndefined: leave unchanged kUnitPoints kUnitMillimeters kUnitPixels (ab CS5) |
line_units | int | 0 | Units for 'Contour' 0, kUnitUndefined: leave unchanged kUnitPoints kUnitMillimeters kUnitPixels (ab CS5) |
customHPoints, customVPoints | float | -1.0 | custom points for horz/vert ruler - What ever that means. -1.0 leave unchanged otherwise : value in points |
key_nudge | float | -1.0 | keyboard nudge increment -1.0 leave unchanged otherwise : value in points |
ppi | float | -1.0 | Point/Inch -1.0 leave unchanged otherwise : value in points |
#include "internal/types.h"
int w_unit (char * m, int u) { char ustr[512];
if (u == kUnitUndefined) strcpy (ustr, "Unit undefined"); else if (u == kUnitPoints) strcpy (ustr, "points"); else if (u == kUnitPicas) strcpy (ustr, "picas"); else if (u == kUnitInches) strcpy (ustr, "inches"); else if (u == kUnitInchesDecimal) strcpy (ustr, "decimal inches"); else if (u == kUnitMillimeters) strcpy (ustr, "mm"); else if (u == kUnitCentimeters) strcpy (ustr, "cm"); else if (u == kUnitCiceros) strcpy (ustr, "ciceros"); else if (u == kUnitAgates) strcpy (ustr, "agates"); else if (u == kUnitPixels) strcpy (ustr, "pixels");
if (m) wlog ("", "# %s : ", m); wlog ("", "%s\n", ustr); return 0; }
int w_units (ItemRef docRef) { float h, v, nudge, ppi;
w_unit ("Horizontal", document::get_units (docRef, kHorizontalUnit)); w_unit ("Vertical", document::get_units (docRef, kVerticalUnit)); w_unit ("Text", document::get_units (docRef, kTextUnit)); w_unit ("Textsize", document::get_units (docRef, kTextSizeUnit)); w_unit ("Print", document::get_units (docRef, kPrintUnit)); w_unit ("Line", document::get_units (docRef, kLineUnit));
h = document::get_custompoints (docRef, kHorizontalUnit); v = document::get_custompoints (docRef, kVerticalUnit); nudge = document::get_keynudge_inc (docRef); ppi = document::get_ppi (docRef);
wlog ("", "Pointsize [%f, %f], key nudge %f, ppi %f\n", h, v, nudge, ppi);
return 0; }
int main () { float h, v, nudge, ppi;
wlog ("", "=== Before ===\n"); w_units (0);
document::set_units ( 0, kUnitPixels, // horiz kUnitAgates, // vert kUnitPixels, // text pt/px kUnitPixels, // textsize pt/px kUnitMillimeters, // print pt/px/mm kUnitMillimeters, // lines pt/px/mm 18.0, 22.0, 2.3456, 120.0);
wlog ("", "=== After ===\n"); w_units (0);
return 0; }
static int get_units(ItemRef docRef = 0, int what = 0)
Get a document unit.
Name | Type | Default | Description |
Return | int | 0 or kUnitPoints kUnitPicas kUnitInches kUnitInchesDecimal kUnitMillimeters kUnitCentimeters kUnitCentimeters kUnitCiceros kUnitAgates (ab CS5) kUnitPixels (ab CS5) |
|
docRef | ItemRef | 0 | Document 0 : current document |
what | int | kHorizontalUnit | Unit to retreive: kHorizontalUnit kVerticalUnit kTextUnit unit for '??' kTextSizeUnit unit for 'text sizes' kPrintUnit unit for 'print' kLineUnit unit for 'contour' |
static float get_custompoints(ItemRef docRef = 0, int what = 0)
InDesign® -API documentation : "custom points for horz/vert ruler".
Name | Type | Default | Description |
Return | float | Current value in points or 0.0 in case of an error | |
docRef | ItemRef | 0 | Document 0 : current document |
what | int | kHorizontalUnit | Value to retreive: kHorizontalUnit kVerticalUnit |
static float get_keynudge_inc(ItemRef docRef = 0)
Keyboard nudge increment.
Name | Type | Default | Description |
Return | float | Current value in points or 0.0 in case of an error | |
docRef | ItemRef | 0 | Document 0 : current document |
static float get_ppi(ItemRef docRef = 0)
Pixel/Points for the document.
Name | Type | Default | Description |
Return | float | Current value in points or 0.0 in case of an error | |
docRef | ItemRef | 0 | Document 0 : current document |
static int get_visible_areas(
ItemRef docRef,
int page,
int flags,
List pageNums,
List cometGroupIDs,
IDTypeList ids,
RectList bboxes,
FloatList visible_sizes,
FloatList sizes,
FloatList percents)
Calculate the visibles areas of Comet groups. The visible area of a frame is the intersection of the following areas :
As you can imagine easily, the procedure for calculating intersections and sizes of arbitrary shapes is very complex. To solve the integrals of the curve pieces (Bézier curves), some interpolations are used. This may cause an average error of 0.03 per thousand (150 times less than the allowed alcohol in alcohol-free beer).
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
page | int | - | page number -1 : all pages otherwise : 1-based page number |
flags | int | - | Control the calculation kUseClippath : In case of images, use the intersection of the current image clip path and the frame shape instead of the frame shape alone. Paths may be arbitrarily complex. kAllowHoles : Normaly holes in images are counted to the image size. You may turn off this behavior by using the kAllowHoles flag. The option is valid only if kUseClippath is active. kCheckTransparenz : As described above, frame transparency is ignored for overlappings. Using image clip path stands in contradiction to this assumption because the whole background is treated as transparent area. Using kCheckTransparenz, the clip path is used only if the frame has
kUseMargins : Only visible parts of frames are counted. Frame parts in the paste board are ignored. If the flag kUseMargins is set, the visible background area is shrinked to page of the frame without the page margins. |
⇨ The following lists are filled on successful return (and may be 0) with one entry for every Comet group. All lists are of same length (instead of 0 values of course). | |||
pageNums | List | - | 1-based page number |
cometGroupIDs | List | - | Comet group-ID |
ids | IDTypeList | - | Object id of Comet group or frame |
bboxes | RectList | - | Comet group/frame bounding box |
visible_sizes | FloatList | - | Visible size of Comet group/frame in square points |
sizes | FloatList | - | Size of bounding box in square points |
percent | FloatList | - | percentage of page used (0.0 - 100.0), see kUseMargins). |
#include "internal/types.h"
int write_areas ( List pageNums, List cometGroups, IDTypeList ids, RectList bboxes, FloatList visible_sizes, FloatList sizes, FloatList percents) { int i = 0; int p = -1; int p1; IDType id; Rect r;
if (list::length (pageNums) == 0) { wlog ("", "document::calc_areas : No frames found\n"); return 0; }
for (i = 0; i < list::length (pageNums); i++) { // Pagenum p1 = list::get (pageNums, i); if (p1 != p) wlog ("", "Page %d\n", p1); p = p1;
// Comet group wlog ("", " Comet group %d\n", list::get (cometGroups, i));
// Id id = idtypelist::get (ids, i); wlog ("", " Id [%d, %d, %d, '%s']\n", idtype::id (id), idtype::id2 (id), idtype::id3 (id), idtype::stringid (id));
// BBoxes r = rectlist::get (bboxes, i); wlog ("", " bbox %f %f %f %f\n", rect::left (r), rect::top (r), rect::right (r), rect::bottom (r));
// Areas wlog ("", " Netto : %f\n", floatlist::get (visible_sizes, i)); wlog ("", " Brutto : %f\n", floatlist::get (sizes, i)); wlog ("", " Percent : %f\n", floatlist::get (percents, i));
}
return 0; }
int main () { int flags = kUseClippath + kUseMargins; List pageNums = list::alloc (); List cometGroups = list::alloc (); IDTypeList ids = idtypelist::alloc (); RectList bboxes = rectlist::alloc (); FloatList visible_sizes = floatlist::alloc (); FloatList sizes = floatlist::alloc (); FloatList percents = floatlist::alloc ();
document::get_visible_areas (0, -1, flags, pageNums, cometGroups, ids, bboxes, visible_sizes, sizes, percents); write_areas (pageNums, cometGroups, ids, bboxes, visible_sizes, sizes, percents);
return 0; }
static int get_links(
ItemRef docRef,
int page,
char* layer,
ItemList resultList)
Get document links.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Document 0 : current document |
page | int | -1 | Page number (1-based). Only links at the given page are retreived. ≤0 : all pages Otherwise : 1-based page number |
layer | String or char* | "" | Layer name. Only links at the given layer are retrieved. "" : All layers Otherwise : layer name |
resultList | ItemList | - | Allocated result list. Using InDesign® the list entries are not document frames. To use the entries, use the functions of the frame::doclink module. Using comet_pdf the result list contains the actual document frames which can also be used in all other frame functions. |
Write the document links into the log file.
int main () { ItemList lks = itemlist::alloc (); ItemRef lk = item::alloc (); ItemRef fr = item::alloc (); char p [5000]; int i;
document::get_links (0, 0, "", lks); for (i = 0; i < itemlist::length (lks); i++) { itemlist::get (lks, lk, i);
frame::doclink::get_frame (lk, fr); frame::doclink::get_path (lk, p);
wlog ("", "Frame %d\t<- %d [%d, '%s']\n", item::getint (fr), item::getint (lk), frame::doclink::get_state (lk), p); }
return 0; }
static int update_links(
ItemRef docRef,
int page = 0,
char* layer = "",
IDTypeList changedLinks = 0)
Update (the) links of the document. You may update the links of a given page and/or layer only. A result list can contain the updated frames and the paths of their links.
Using comet_pdf the function is available but has no effect and the result list remains empty always.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Document 0 : current document |
page | int | -1 | Page number. Only links at the given page are updated. -1 : all pages otherwise : 1-based page number |
layer | String or char* | "" | Layer name. Only links at the given layer are updated. "" : All layers otherwise : layer name |
changedLinks | IDTypeList | 0 | list of changed links. idtype::id will return the UID of the updated frame of the list entries (On text chains the first frame of the chain). idtype::stringid will return the complete path of the link of the list entries. |
int main () { IDTypeList updated = idtypelist::alloc (); IDType * p;
document::update_links (0, 1, "", updated);
for (p = idtypelist::first (updated); p; p = idtypelist::next (updated)) { wlog ("", "# %d\t'%s'\n", idtype::id (p), idtype::stringid (p)); }
return 0; }
static int export_styles(
ItemRef docRef = 0,
char* destPathAndBaseName = 0,
int fileFlag = 1)
XML-Export of document styles and colors.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Document 0 : current document |
destPathAndBaseName | String or char* | "" | Path and base name for export files. Styles export will be written to destPathAndBaseName_Styles.xml
and colors to destPathAndBaseName_Graphic.xml "" : Path and base name of docRef (must not be new and unsaved in this case!) |
fileFlag | int | 1 | Remove existing export files? 0 : No 1 : Yes |
static int get_styles(
ItemRef docRef,
char* styleClass,
StringList resultList)
Collect all style names of a document. The names of all available styles of one class will be including their folder path inserted into a list. The path separator is ':'.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document 0 : current document |
styleClass | char* oder String | - | Which style names should be collected? "parastyles" : Paragraph styles "charstyles" : Character styles "objstyles" : Object styles "tablestyles" : Table styles "cellstyles" : Cell styles |
resultList | StringList | - | Result list Please note
|
Write all available paragraph styles of the current document into the log file.
int main () { StringList li = stringlist::alloc (); char * str;
document::get_styles (0, "parastyles", li);
for (str = stringlist::first (li); str; str = stringlist::next (li)) { wlog ("", "--%s--\n", str); }
stringlist::release (li); return 0; }
static int import_styles(
ItemRef docRef,
char* whatStyles,
char* sourceDocument,
int clashResolution = 0)
Import styles from another document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document 0 : current document |
whatStyles | char* oder String | - | Types of formats to import. The following (case insensitive) styles
types are supported: "paraStyles" : Paragraph styles "charStyles" : Character styles "textStyles" : Paragraph and character styles "tableStyles" : Table styles "cellStyles" : Cell styles "tableAndCellstyles" : Table and cell styles "tocStyles" : Table of content styles "strokeStyles" : Stroke styles (Not supported by comet_pdf.) "objectStyles"</i> : Object styles "all" : All styles |
sourceDocument | char* oder String | - | Complete path of the document from which the styles are to be imported. |
clashResolution | int | 0 | Strategy for resolving conflicts with name matches 0 : Does not import styles whose names clash with existing items br/> 1 : Overwrite existing styles whose names clash with imported items br/> 2 : Renames imported styles whose names clash with existing items to preserve existing items
Note for comet_pdf : If only cell styles are imported
missing paragraph styles used in cell styles are also imported.
But existing paragraph styles are not overwritten in this csse.
If i.e. the cell style Z is imported with the paragraph style A, then A is imported if
there is not yet a paragraph style A. If A already exists, the paragraph style A is left
unchanged. |
result = document::import_styles (0, "tableAndCellStyles", "$DESKTOP/naiv.indd", 0);
static int show_folio(ItemRef docRef = 0)
Open the Folio preview of a given document. Supported since InDesign® CS 5.5.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Document 0 : current document |
static int get_notes_printable(ItemRef docRef = 0)
static int set_notes_printable(ItemRef docRef = 0, int newState = 0)
static int get_masterpages(
ItemRef docRef,
IDTypeList resultList,
int unusedOnly = 0,
int sortedByBasedOn = 1)
Get information about the parent pages/spreads of a given document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document 0 : current script document |
resultList | IDTypeList | - | Allocated list for results. The list entries containing the following values idtype::stringid () : Name of parent spread idtype::id () : UID idtype::id2 () : Number of parent pages in spread idtype::id3 () : UID of ancestor |
unusedOnly | int | 0 | since V4.1.6 R25778 Get only the unused parent pages of the document |
sortedByBasedOn | int | 1 | ab V4.1.6 R25778 Sort order in result list: 1 : The result list is sorted such that parents with other parents applied to them are later in the list than the parents they derive from. 0 : Same sequence order like in panel Pages. |
int main () { IDTypeList masters = idtypelist::alloc (); IDType master;
document::get_masterpages (0, masters); for (master = idtypelist::first (masters); master; master = idtypelist::next (masters)) { wlog ("", "%s [UID %d, %d page(s), Ancestor %d]\n", idtype::stringid (master), idtype::id (master), idtype::id2 (master), idtype::id3 (master)); }
return 0; }
static int import_masterpage(
ItemRef docRef,
char* orgPath,
char* master_name,
int overrideExisting = 0,
int openAsCopy = 0)
Import/update parent spread(s) of a document from another document. All ancestors of the parent spread are automatically imported/updated too.
If the source document is not already opened, the document is opened in the background and closed at the next idle time. Do NOT change this document in this case!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | destination document 0 : current script document |
orgPath | String or char* | - | complete path to the source document |
master_name | String or char* | - | complete parent spread name (C-Parent) All ancestors of this parent are imported/updated too. |
overrideExisting | int | 0 | Update existing parent spreads? 0 : no 1 : yes. All overrides of the updated parent spreads will be removed automatically in this case. |
openAsCopy | int | 0 | Open mode of file 0 : Open normally. If the file is already open, this document will be used. 1 : Open as copy. Unsaved changes in another document window of the same source file are ignored. |
int main () { int res;
res = document::import_masterpage ( 0, "$DESKTOP/myParents.indd", "C-Parent", 1);
wlog ("", "import_masterpage result %d\n", res); return 0; }
static int import_masterpages(
ItemRef docRef,
char* sourceDocument,
int clashResolution = 0)
Import all parent pages from another document. Deleted parent page frames that have been overwritten in the target (see frame::is_overriden_masteritem) are retained during import.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document 0 : current document |
sourceDocument | char* oder String | - | Complete path of the document from which the parent spreads are to be imported. |
clashResolution | int | 1 | Strategy for resolving conflicts with name matches 1 : Overwrite existing parents whose names clash with imported items br/> 2 : Renames imported parents whose names clash with existing items to preserve existing items |
int main () { int res = document::import_masterpages (0, "$DESKTOP/m_src.indd", 1);
wlog ("", "Import masterpages result : %d", res); return 0; }
static int remove_masterpage(ItemRef docRef, char* master_name)
Remove a parent spread from a given document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | destination document 0 : current script document |
master_name | String or char* | - | Complete parent spread name (C-Parent) |
int main () { int res;
res = document::import_masterpage ( 0, "$DESKTOP/myMasters.indd", "C-Parent", 1);
wlog ("", "import_masterpage result %d\n", res); return 0; }
static int move_masterpage(
ItemRef docRef,
char* master_name,
char* before)
Move a parent page entry in the list of parent pages on the panel Pages.
The call has no influence on the appearance of the document. It only changes the order of the parent pages in the panel Pages
For some reason that we cannot understand, the instruction cannot be undone.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | destination document 0 : current script document |
master_name | String or char* | - | complete parent spread name (C-Parent) |
before | String oder char* | - | Before which parent the entry spread should be moved? "" or non-existing parent page : Move to the end |
static int dump_uidtranstable(ItemRef docRef = 0)
Internal use only.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | destination document 0 : current script document |
static int cometgroup_recreated(
ItemRef docRef,
int oldGroupID,
int newGroupID)
Reset a Comet group ID. After replacing products (Comet groups) you may wish to have the same Comet group ID for the new Comet group. To solve this problem, keep the current ID in a variable, replace the Comet group and reset the new Comet group ID by the old one.
Use existing Comet group IDs only! Wrong numbers may cause serious errors!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | destination document 0 : current script document |
oldGroupID | int | - | Comet group ID before replacing |
newGroupID | int | - | Group ID after replacing |
Collect all Comet group of a document and replace some of them by prepared snippets. To run the script, please create a new action first with the implementation given in the next example and replace MY_COMPARE_SCRIPT by the ID of this new action.
#include "internal/types.h"
int get_snippet (IDType id) { if (idtype::id (id) == 0) return 0; if (strcmp (idtype::stringid (id), "109007") == 0) return 617; if (strcmp (idtype::stringid (id), "109507") == 0) return 621; if (strcmp (idtype::stringid (id), "107507") == 0) return 623;
return 0; }
IDType get_id (ItemRef fr, IDType id) { int i; char base [255]; char slot [255];
idtype::set_id (id, 0); if (!frame::get_cometgroup (fr)) return id;
for (i = 0; i < 2; i++) { if (i == 0) strcpy (base, "BuiltBy"); else strcpy (base, ""); idtype::set_id (id, placeholder::get_value (fr, sprintf (slot, "%d%s", base, "ID"))); idtype::set_id2 (id, placeholder::get_value (fr, sprintf (slot, "%s%s", base, "ID2"))); idtype::set_id3 (id, placeholder::get_value (fr, sprintf (slot, "%s%s", base, "ID3"))); idtype::set_stringid (id, placeholder::sget_value (fr, sprintf (slot, "%s%s", base, "StringID")));
if (idtype::id (id)) break; }
return id; }
int replace (ItemList oldFrames) { ItemList newFrames = 0; ItemRef fr = item::alloc (); IDType id = idtype::alloc (); int snippet; float l, t, r, b; int pg, gid, new_gid; char lay [512];
while (1) { // Sanity check itemlist::get (oldFrames, fr, 0); if (!frame::is_valid (fr)) break;
// Do we have to replace this Comet group? snippet = get_snippet (get_id (fr, id)); if (!snippet) break;
// Get old states pg = page::get (fr); gid = frame::get_cometgroup (fr); frame::get_layer (fr, lay); itemlist::bbox (oldFrames, &l, &t, &r, &b);
wlog ("", "'%s' replace by snippet %d\n", idtype::stringid (id), snippet);
// Remove old, create new itemlist::remove_items (oldFrames); newFrames = document::place_items (0, 0, 0, snippet, l, t, pg, lay);
// Reset comet group id itemlist::get (newFrames, fr, 0); new_gid = frame::get_cometgroup (fr); document::cometgroup_recreated (0, gid, new_gid);
break; // ready }
item::release (fr); idtype::release (id); itemlist::release (newFrames);
return 0; }
int main () { ItemListList lli; ItemList li; ItemList docFrames = itemlist::allframes ();
if (gRun > 1) return 0;
lli = itemlist::logical_groups (docFrames, kSearchDocument, "", 1, "script", MY_COMPARE_SCRIPT);
for (li = itemlistlist::first (lli); li; li = itemlistlist::next (lli)) { replace (li); }
itemlist::release (docFrames); itemlistlist::release (lli);
return 0; }
Function for the above example.
int main () { int group1 = frame::get_cometgroup (gMasterFrame); int group2 = frame::get_cometgroup (gCheckFrame);
if (!gCheckFrame) { if (!group1) return 0; return 0; }
return (group1 != group2); }
static int get_pageref(
ItemRef outRef,
ItemRef docRef,
int pg)
Get the UID of a page.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
outRef | ItemRef | - | allocated ItemRef for the resulting page ref |
docRef | ItemRef | - | document 0 : current script document |
pg | int | - | 1-based index of interested page |
int main () { int pg = page::get (gFrame); int indexInSpread; int spread = page::get_spread (0, pg, &indexInSpread); ItemRef pageRef = item::alloc (); ItemRef spreadRef = item::alloc ();
document::get_pageref (pageRef, 0, pg); document::get_spreadref (spreadRef, 0, spread);
wlog ("", "Spread %d (%d), Seite %d (%d), %d. page in Spread\n", spread, item::getint (spreadRef), pg, item::getint (pageRef), indexInSpread);
return 0; }
static int get_spreadref(
ItemRef outRef,
ItemRef docRef,
int spreadIndex)
Get the UID of a spread given by its index. To get the spread index of a page, use page::get_spread.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
outRef | ItemRef | - | allocated ItemRef for the resulting page ref |
docRef | ItemRef | - | document 0 : current script document |
pg | int | - | 0-based spread index of interest. To get the spread index of a page, use page::get_spread. |
int main () { int pg = page::get (gFrame); int indexInSpread; int spread = page::get_spread (0, pg, &indexInSpread); ItemRef pageRef = item::alloc (); ItemRef spreadRef = item::alloc ();
document::get_pageref (pageRef, 0, pg); document::get_spreadref (spreadRef, 0, spread);
wlog ("", "Spread %d (%d), Seite %d (%d), %d. page in Spread\n", spread, item::getint (spreadRef), pg, item::getint (pageRef), indexInSpread);
return 0; }
static int has_overset(
ItemRef docRef,
ItemList frames = 0,
ItemList tables = 0,
IDTypeList cells = 0)
Is there at least one text or table cell with overset text in the document?
Name | Type | Default | Description |
Return | int | 0 : No overset text or error 1 : At least one text frame or one table cell has overset text |
|
docRef | ItemRef | - | document 0 : current script document |
frames | ItemList | 0 | (out parameter) Frames with text overset |
tables | ItemList | 0 | (out parameter) Tables with cells with text overset. The list has the same length as cells and the i-th entry in the list is the table reference of the i-th entry in cells. |
cells | IDTypeList | 0 | (out parameter) The list contains an entry of type IDType for every overseted cell with the
following data: idtype::id : 0-based column idtype::id2 : 0-based row idtype::id3 : UID of table. See item::define for more information about how to use UIDs. Alternatively, the corresponding table reference can also be determined from the list tables using the same list index. |
int main () { ItemList frames = itemlist::alloc (); ItemList tables = itemlist::alloc (); IDTypeList cells = idtypelist::alloc (); int ov;
ov = document::has_overset (0, frames, tables, cells); if (ov) { wlog ("", "# Oversets : %d frame(s), %d table(s), %d cells(s)\n", itemlist::length (frames), itemlist::length (tables), idtypelist::length (cells)); }
return 0; }
Create red frames over all table cells with overset. The red frames should be created on the layer 'Overset.
#include "internal/types.h" #include "internal/table.h" #include "internal/text.h" #include "internal/products.h"
int main() { checkAndMarkOversets(); return 0; }
int checkAndMarkOversets() { ItemList frames = itemlist::alloc(); ItemList tables = itemlist::alloc(); IDTypeList cells = idtypelist::alloc(); int ov; char * layerName = "Overset";
layer::remove(layerName); layer::add(layerName, ""); ov = document::has_overset(0, frames, tables, cells); if (ov) handleOversetTable(tables, cells);
itemlist::release(frames); itemlist::release(tables); idtypelist::release(cells);
return 0; }
int handleOversetTable(ItemList tableList, IDTypeList cellList) { ItemRef fr = item::alloc(); ItemRef nFrame = item::alloc(); IDType idType; char * layerName = "Overset"; char * colorName = "Overset"; int c, r; Table t = table::alloc(); float x, y, x2, y2; float fx, fy, fx2, fy2; int i, j;
color::define_cmyk(colorName, 0.0, 1.0, 1.0, 0.0); for (i = 0; i < itemlist::length(tableList); i++) { itemlist::get(tableList, t, i); Tabelle aus der Liste abfragen idType = idtypelist::get(cellList, i); if (table::is_valid(t)) { c = idtype::id(idType); r = idtype::id2(idType); if (c < table::columns(t) && r < table::rows(t)) { table::get_cellbox(t, c, r, kFrameRelative, &x, &y, &x2, &y2, fr); frame::bbox(fr, &fx, &fy, &fx2, &fy2); frame::create2(nFrame, kRectangle, fx + x, fy + y, fx + x2, fy + y2, page::get(fr), layerName); frame::color(nFrame, colorName); frame::set_blending(nFrame, kBlendingBasic, 20.0); } } }
table::release(t); item::release(fr); item::release(nFrame);
return 0; }
static int write_frame_info(
ItemRef document,
int frameSearchFlags,
int documentType,
int conflictBehavior,
int frameType = 0,
int page = -2,
LinkList placeholders = 0)
Store all information about frames in the document to the data sources. More information at Frame infos
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
document | ItemRef | - | Document |
frameSearchFlags | int | kUseDefault | How should frame infos to overwrite be identified? See frame::write_frame_info |
documentType | int | kLocalDoc | In which document scope should we search for existing frame infos? See frame::write_frame_info |
conflictBehavior | int | kThrowError | Behavior when multiple search results are found per frame See frame::write_frame_info |
frameType | int | - | Frame type to write 0: All 1: Text frame 2: Graphic frame |
page | int | -2 | From which page should the frames be written? -2: All pages |
placeholders | LinkList | 0 | Only respect placeholders in this list |
Write all frames of the document
int main () { return document::write_frame_info(gDocument); }
Only write graphic frames from page 4
int main () { document::write_frame_info(gDocument, 2, 4); return 0; }
static int apply_frame_info(
ItemRef document,
int propertyFlags,
int searchType,
int documentType,
int page = -2,
int frameType = 0,
LinkList placeholders = 0)
Restore saved information about a frame from the data sources and set it back to the frames. More information at Frame infos
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
document | ItemRef | - | Document |
propertyFlags | int | - | Which information should be restored? See frame::apply_frame_info |
frameSearchFlags | int | kUseDefault | How should the document source be identified? See frame::apply_frame_info |
documentType | int | kLocalDoc | How should the stored frame be identified? See frame::apply_frame_info |
conflictBehavior | int | kThrowError | Behavior when multiple search results are found per frame See frame::apply_frame_info |
page | int | -2 | Restore frame information on which page? -2: All pages |
frameType | int | 0 | Only respect frames of type 0: All 1: Text frame 2: Graphic frame |
placeholders | LinkList | 0 | Only respect placeholders in this list |
Restore all properties of all frames in the current document
#include "internal/frameinfos.h"
int main () { int propertyFlags = kApplyScriptTags + kApplyXPosAbs + kApplyYPosAbs + kApplyWidth + kApplyHeight + kApplyFrameRotate + kApplyFrameSkew + kApplyImageXOffset + kApplyImageYOffset + kApplyImageXScale + kApplyImageYScale + kApplyImageRotate + kApplyImageSkew;
document::apply_frame_info(gDocument, propertyFlags, kUseDefault, kLocalDoc, kThrowError); return 0; }
static int delete_frame_info(
ItemRef docRef,
int frameSearchFlags = kUseDefault,
int documentType = kLocalDoc,
int conflictBehavior = kThrowError,
int page = -2,
int frameType = 0,
LinkList placeholders = 0)
Delete saved information about the document's frames from the data sources.
Important: This function only deletes frame infos for the current frames of the document. This is a convenience function for easily gathering the document's frames. More information at Frame infos
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
document | ItemRef | - | Document |
frameSearchFlags | int | kUseDefault | How should the document source be identified? See frame::apply_frame_info |
documentType | int | kLocalDoc | How should the stored frame be identified? See frame::apply_frame_info |
conflictBehavior | int | kThrowError | Behavior when multiple search results are found per frame See frame::apply_frame_info |
page | int | -2 | Restore frame information on which page? -2: All pages |
frameType | int | 0 | Only respect frames of type 0: All 1: Text frame 2: Graphic frame |
placeholders | LinkList | 0 | Only respect placeholders in this list |
Delete all properties of all frames in the current document
#include "internal/frameinfos.h"
int main ()
{
document::delete_frame_info(gDocument);
return 0;
}
static int delete_frame_info2(ItemRef docRef)
Delete saved frame infos for this document data sources.
Important: This function deletes all frame infos ever stored for the current document. More information at Frame infos
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
document | ItemRef | - | Document |
Delete all stored frame infos of the current document
int main () { document::delete_frame_info2(gDocument); return 0; }
static int create_mission_ui(ItemRef docRef, ItemList frames = 0)
Opens the dialog for creating missions.
A frame list can be provided as a parameter to create missions for these frames. More information at Missions
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
document | ItemRef | - | Document |
duplicateBehavior | int | 0 | What should happen if the mission already exists? 0 - Don't create 1 - Move the first existing mission to bottom of list and delete the rest 2 - Create new mission as duplicate |
frames | ItemList | 0 | Frames for which missions should be created. |
Shows the input dialog with different behavior for duplicates depending on keys pressed. Can create missions for the selected frames.
int main() { ItemList selected;
selected = itemlist::selected();
if (gRun == 1) { if (system::shiftkey()) { document::create_mission_ui(gDocument, 1, selected); // Move } else if (system::cmdkey()) { document::create_mission_ui(gDocument, 2, selected); // Duplicate } else { document::create_mission_ui(gDocument, 0, selected); // Skip } }
itemlist::release(selected);
return 0; }
static int execute_missions(
ItemRef docRef,
int deleteAfterDone = 1,
int alsoDeleteFailed = 0)
Executes all Missions of the document. A frame list can be provided as a parameter to create missions for these frames. More information at Missions
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
document | ItemRef | - | Document |
deleteAfterDone | int | 1 | Delete missions after execution? 0 - No 1 - Yes |
alsoDeleteFailed | int | 0 | Also delete missions which failed to execute? Has no effect when deleteAfterDone is 0. 0 - No 1 - Yes |
Executes all missions of the document. Successful ones are deleted, failed ones not.
int main () { document::execute_missions(gDocument, 1, 0);
return 0; }
static int count_missions(ItemRef docRef, int* count)
Counts the number of missions in the document. More information at Missions
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
document | ItemRef | - | Document |
count | int* | - | Result mission count |
Shows a message containing the number of missions in the document.
int main () { int count = 0;
document::count_missions(gDocument, &count); showmessage("%d", count);
return 0; }
static int delete_missions(ItemRef docRef)
Deletes all missions from the document. More information at Missions
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
document | ItemRef | - | Document |
Delete all missions of the document.
int main () { document::delete_missions(gDocument);
return 0; }
static int remove_duplicate_missions(ItemRef docRef)
Removes all duplicates of all missions in the document, leaving only one instance of each mission.
More information at Missions
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
document | ItemRef | - | Document |
Delete all missio duplicates s of the document.
int main () { document::remove_duplicate_missions(gDocument);
return 0; }
static int prepare_translations(
ItemRef docRef,
int placeholderID,
int autoStore,
int get_record_id_func,
IDType recordID,
int behavior = 0)
Prepare a document for automatic translations. All existings text placeholders are removed first. Then, every piece of text is linked against a new placeholder. This pieces are delimited by (of course) the text begin and end and by tables, inlines and table cells. To calculate new record IDs, the function get_record_id_func is called for every new placeholder.
The given placeholder placeholderID must by defined and of type text!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script document |
placeholderID | int | - | ID of a defined text placeholder in the data pool |
autoStore | int | - | Automatically store the new placeholders.? 0 : no 1 : yes, the store script is called for every new placeholder |
get_record_id_func | func_ptr | - | Name of function to calculate the new record IDs. You simply give it the name of an existing function
of type int my_function (IDType myRecordID, int placeholderID) The IDType myRecordID must be declared and allocated outside this function. See example to learn more. Return value of get_record_id_func 1 : Create and link the placeholder 0 : Do not create placeholder |
recordID | IDType | - | Allocated IDType for calculations in calls to get_record_id_func |
behavior | int | 0 | How to deal with existing placeholders of the text? 0 : Replace all placeholders 1 : Retain placeholders with ID placeholderID, replace all others 2 : Retain all placeholders |
Indeed, its easy! In the example the function get_record_id is implemented with the approriate type. Before using it, we have to allocate an IDType. Thats all, you now can call prepare_translations. Its creating the placeholders as described above and will call get_record_id everytime a new placeholder is needed.
int main () { IDType recordID = idtype::alloc ();
idtype::set_id (recordID, 100); document::prepare_translations (0, 360, 1, get_record_id, recordID);
return 0; }
int get_record_id (IDType rid, int placeholderID) { idtype::set_id (rid, idtype::id (rid)+1); idtype::set_id2 (rid, 0); idtype::set_id3 (rid, 0); idtype::set_stringid (rid, "");
return 1; }
static int link_with_unique_placeholder(
ItemRef docRef,
int placeholderID,
int autoStore,
int get_record_id_func,
IDType recordID)
Synonym for prepare_translations.
static int schwarzfilmtausch(ItemRef docRef)
Prepare document for the so called 'Schwarzfilmtausch'. To avoid moving around colored parts of the document we lock all frames and all table row heights of the document. In addition, all layout rules and all nails and magnets are removed from the document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script document |
static int get_blendingspace(ItemRef docRef)
Get the transparency blending space of a document.
Name | Type | Default | Description |
Return | int | -1 : Error 1 : RGB 2 : CMYK |
|
docRef | ItemRef | - | document 0 : current script document |
static int set_blendingspace(ItemRef docRef, int blendSpace)
Set the transparency blending space of a document.
If the document is printed later, take care on the appropriate setting here! Wrong settings may lead to wrong print results!
Here you can see the same frames at first in a RGB transparency blending space and then in CMYK:
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script document |
blendSpace | int | - | new transparency blending space 0 : Default 1 : RGB 2 : CMYK |
Toggle transparency blending space.
int main () { int blendingspace = document::get_blendingspace (0);
if (blendingspace == 1) document::set_blendingspace (0, 2); else if (blendingspace == 2) document::set_blendingspace (0, 1);
return 0; }
static int preflight(
ItemRef docRef,
char* profile,
char* output,
int maxlen = 0)
Preflight a document to check for errors. The preflight profile has to be defined by its name or by a complete path to an idpp file. To define preflight profiles in InDesign® (Desktop) you may use the Preflights panel. Under InDesign® Server you can install new preflight profiles by calling this line of JavaScript:
app.loadPreflightProfile(File(profilepath));
Under comet_pdf the commend is NOP.
Name | Type | Default | Description |
Return | int | Fehlercode or 0 1289 (preflightNotEmptyErr) : Preflight successfully done and found some errors. |
|
docRef | ItemRef | - | Document 0 : Current script document |
profile | String or char* | - | Name or path of preflight profile. If you use a path (extension idpp) please take care about its name: File name and profile name must be equal. Otherwise every call of the function will create a new numbered) version of the profile. |
output | String or char* | - | Allocated result string "" : Results will be written into this string. Take care to allocate this string big enough when using char*! Complete path with extension 'pdf' or 'txt' : Write results to the given file. If a file already exists, it will be overridden. InDesign® Server does NOT support PDF export here! |
maxlen | int | 0 | Size of output in bytes incl. the closing 0. The parameter is used only if output is empty ("") and of type char*. Results longer than maxlen are cut off at maxlen-1 bytes. |
int main () { char txt [100000]; int result;
if (system::shiftkey ()) strcpy (txt, "$DESKTOP/aaa.pdf"); result = document::preflight (0, "$DESKTOP/aaa.idpp", txt); wlog ("", "%d\n-------------------\n%s\n", result, txt);
return 0; }
static int export_color_profiles(
ItemRef docRef,
char* destfolder,
char* destXML = 0)
Export color profiles of a given document. The function exports the RGB and CMYK color profiles used in a given document. If the document uses a global color space, the profile of the workspace space is exported.
Name | Type | Default | Description |
Return | int | Fehlercode or 0 | |
docRef | ItemRef | - | Document 0 : Current script document |
destfolder | String or char* | - | Export destination for the icc file. The export copies the profile file into the subfolder rgb or cmyk of the given folder. Missing folders are created automatically Existing target files are overwritten. |
destXML | String or char* | 0 | Full path of a colorprofiles.xml.
The profile data of the exported color profiles are inserted into/updated in the specified XML. If the XML does not exist, it is created.
0: Ignore |
int main () { document::export_color_profiles (0, "$DESKTOP/aaabbb", "$DESKTOP/aaabbb.xml");
return 0; }
static int get_color_profiles(
ItemRef docRef,
char* rgbProfile = 0,
char* cmykProfile = 0,
char* priority = 0)
Determine the names of the color profiles set in the document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document 0 : Current script document |
rgbProfile | String or char* | 0 | Name of the RGB profile 0 : Ignore return value |
cmykProfile | String or char* | 0 | Name of the CMYK profile 0 : Ignore return value |
priority | String or char* | 0 | Rendering Intention. One of the following values is returned: perceptual saturation relative absolute unknown 0 : Ignore return value |
static int clean_storyscrap(ItemRef docRef = 0)
Remove unused text stories of a document. All documents, containing text imported by priint:priint:comet InDesign® Plug-Ins prior v4.0.5 R16180 are containing unused objects which may lead to some problems while using the documents under some rare circumstances. Using document::clean_storyscrap you can clean up these documents.
Remarks:
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document 0 : Current script document |
static int show_invisibles(ItemRef docRef = 0, int state = -2)
Show/Hide invisible characters of texts of the document.
Name | Type | Default | Description |
Return | int | Old state -1 : Error 0 : Invisibles hidden 1 : Invisibles shown |
|
docRef | ItemRef | 0 | Document 0 : Current script document |
int | state | -2 | New state -2 : Query state only -1 : Toggle 0 : Hide invisibled 1 : Show invisibled |
static int individualization(ItemRef docRef, char* dataFilePath)
Serialize a document, see here for more information about serializations.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Document to serialize, see hier 0 : current front document |
dataFilePath | char* oder String | - | Complete path to serialization data file see here The data type String si supported since v4.1 R23901! |
static ItemList linked_urls(ItemRef docRef = 0)
Get all frames of a document which have a Web Image. General information about Web Images can be found here.
Name | Type | Default | Description |
Return | ItemList | New ItemList containing only frames from the document with Web Images. Must be deleted using itemlist::release! | |
docRef | ItemRef | 0 | Document 0: Current script document |
Get the linked and embedded frames of a document
int main() { ItemList linked = document::linked_urls(); ItemList embedded = document::embedded_urls(); int linkedCount = 0; int embeddedCount = 0;
if (linked) { linkedCount = itemlist::length(linked); }
if (embedded) { embeddedCount = itemlist::length(embedded); }
showmessage("%d frames are linked\n%d frames are embedded", framesCount, linkedCount, embeddedCount);
itemlist::release(selected); if (linked) { itemlist::release(linked); } if (embedded) { itemlist::release(embedded); }
return 0; }
static ItemList embedded_urls(ItemRef docRef = 0)
Get all frames of a document which have an embedded Web Image. General information about Web Images can be found here.
Name | Type | Default | Description |
Return | ItemList | New ItemList containing only frames from the document with embedded Web Images. Must be deleted using itemlist::release! | |
docRef | ItemRef | 0 | Document 0: Current script document |
Get the linked and embedded frames of a document
int main() { ItemList linked = document::linked_urls(); ItemList embedded = document::embedded_urls(); int linkedCount = 0; int embeddedCount = 0;
if (linked) { linkedCount = itemlist::length(linked); }
if (embedded) { embeddedCount = itemlist::length(embedded); }
showmessage("%d frames are linked\n%d frames are embedded", framesCount, linkedCount, embeddedCount);
itemlist::release(selected); if (linked) { itemlist::release(linked); } if (embedded) { itemlist::release(embedded); }
return 0; }
static ItemList check_url_links(
ItemRef docRef = 0,
ItemList outDated = 0,
ItemList error = 0,
int flags = 0)
Check all Web Images of the document. General information about Web Images can be found here.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Document 0: Current script document |
outdated | ItemList | 0 | After execution, this list contains the frames with outdated images. |
error | ItemList | 0 | After execution, this list contains the frames for which the status check failed. |
flags | int | 0 | Flags 1 : Show progress |
check all link states
int main() { ItemList outDatedFrames = itemlist::alloc(); ItemList errorFrames = itemlist::alloc(); int i = 0; int outDatedFramesCount = 0; int errorFramesCount = 0;
document::check_url_links(gDocument, outDatedFrames, errorFrames, 1); errorFramesCount = itemlist::length(errorFrames); outDatedFramesCount = itemlist::length(outDatedFrames);
showmessage("%d frames are out of date.\nCould not get state for %d frames.", outDatedFramesCount, errorFramesCount);
itemlist::release(errorFrames); itemlist::release(outDatedFrames);
return 0; }
static ItemList update_url_links(ItemRef docRef = 0, int flags = 0)
Update all Web Images of the document modified on server side. General information about Web Images can be found here.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Document 0 : Current script document |
flags | int | 0 | Flags 1 : Show progress |
int main () { ItemList missing = itemlist::alloc (); ItemList outdated = itemlist::alloc (); int result;
if (!system::shiftkey ()) { result = document::update_url_links (0, 1); if (result != 0) { showmessage ("Error %d while checking Web Images.", result); } } else { result = document::check_url_links (0, outdated, missing, 1); if (result == 0) { showmessage ("%d missing images, %d outdated images", itemlist::length (missing), itemlist::length (outdated)); } else { showmessage ("Error %d while checking Web Images.", result); } }
return 0; }
static ItemList remove_url_links(ItemRef docRef = 0)
Remove the Web Image links from all frames of the document. The images in the frames are untouched, only the links to the Web Images (th URLs) are removed. Generell information about Web Images you will find here.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Document 0 : Current script document |
int main () { document::remove_embedded_urls(); return 0; }
static char* get_image_url_folder(ItemRef docRef = 0)
Get the path for the downloads of Web Images of the document. Generell information about Web Images you will find here.
Name | Type | Default | Description |
Return | char* | Path for Web Image downloads of the document. The document must not be new and UNSAVED.
The return value must not be changed and will be overwritten in subsequent calls of the function. See here to learn more about functions returning r/o char* values. |
|
docRef | ItemRef | 0 | Document 0 : Current script document |
static int get_placeholder_visibility(ItemRef docRef = 0)
Get the visibility of document placeholders.
The function has no meaning using comet_pdf. Use option -ap here to show the placeholders in the resulting PDF, see here for more information.
Name | Type | Default | Description |
Return | int | Current visibiltiy 0 : Hidden 1 : Visible 2 : Visible with state -1 : Error |
|
docRef | ItemRef | 0 | Document 0 : Current script document |
static int set_placeholder_visibility(
ItemRef docRef = 0,
int newState = 0,
int suppressUI = 0)
Set the visiblity of document placeholders.
The function has no meaning using comet_pdf. Use option -ap here to show the placeholders in the resulting PDF, see here for more information.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Document 0 : Current script document |
newState | int | 0 | New visiblity 0 : Hide 1 : Show 2 : Show with Status |
suppresUI | int | 0 | On large documents, a progress is shown automatically. Shall I suppress the progress bar? 0 : No, show progress bar if needed 1 : Yes, suppress progress bar zeigen No effect in Illustrator |
static int notes::export_(
ItemRef docRef = 0,
char* destPath = 0,
String destString = 0,
int flags = 4)
Export Comet notes of a document. Be careful with destString, its a String not a char*.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | valid document 0 : current document |
destPath | String or char* | "" | Destination path for the resulting xml file. If destString is defined and not 0, destPath is ignored. |
destString | String | 0 | Destination string for export, must be allocated using string::alloc. If the value is 0 destPath is used to export. |
flags | int | kUseDocumentPath | export flags 0 : no flags kUseDocumentPath : Use document path and name with the extension xml as export file kNoHiddenNotes : Suppress exporting hidden notes |
Export all Comet notes of the current document. The document must not be new (but can be modified).
int main () { int result;
result = document::export_notes (); wlog ("# Exporting all notes returned result code %d\n", result);
return 0; }
Export to a string.
#include "internal/types.h"
int main () { int result; String d = string::alloc (); char * s; XMLTree tree; char title [512]; long id;
result = document::export_notes (0, "", d); if (result == 0) wlog ("# %d chars exported\n", string::length (d)); else { wlog ("# Export to string failed with error %d\n", result); return 0; }
// Using export in an xml tree wlog ("", "Notes of current document\n"); tree = xmlquery::parse (string::get (d)); xmlquery::send (tree, "select title, id node notes.note orderby title"); xmlquery::output (tree, kString, title, 511); xmlquery::output (tree, kInt, &id); xmlquery::exec (tree); while (xmlquery::fetch (tree)) { wlog ("", "\t%s : %d\n", title, id); } xmlquery::close (tree);
// Internal usage of export s = alloc (string::length (s)+1); strcpy (s, string::get (d));
wlog ("", "\n\n"); wlog ("", s); wlog ("", "\n\n");
release (s); release (d);
return 0; }
static int notes::import(
ItemRef docRef = 0,
char* srcPath = 0,
char* srcString = 0,
int flags = 6)
Import Comet notes into an InDesign® document. Comet notes are give as XML file or as a string containing the XML data of the Comet notes. You must have ToDoList installed.
Here you can find information about the used XML format
Please take care on the installation hints for importing end exporting PDF comments
Name | Type | Default | Description |
Return | int | \ URL[error code]{../errorcodes.html} or 0 | |
docRef | ItemRef | 0 | Valid document reference 0 : current document |
srcPath | String or char* | "" | Source file 0 or "" : Ask for XML file. Ignored, if srcString is not 0 "pdf" : Import of PDF comments from the PDF next to document Complete path of PDF: Import of PDF comments from this PDF |
srcString | String or char* | 0 | XML data for Comet notes to be imported. If empty, srcPath is taken. |
flags | int | kUseDocumentPath + kReplaceNotes | Import flags 0 : no more information kUseDocumentPath : Search for import in the same folder as the document kReplaceNotes : Remove all existing notes before importing. kSuppressExternalUpdate : [InDesign® Server only] Notes imported by InDesign® Server are hidden by default. If you open the document using InDesign® (Desktop) later, these notes become visible by default. Suppress this behavior by setting the flag kSuppressExternalUpdate. Later calls to import_notes can override this setting. |
Replace all notes by the notes given in xxx.xml, while xxx is the documents name.
int main () { document::import_notes (); return 0; }
Remove all notes from a document. (use "" as srcPath, not 0 with defualt options). int main () { document::import_notes (0, 0, ""); return 0; }
[InDesign® Server]Import some notes into a document and export the document and all its notes to a PDF. If someone opens the document using InDesign® Desktop later, the notes should be invisible.
#include "internal/types.h"
int main () { int flags = kUseDocumentPath + kReplaceNotes;
flags += kSuppressExternalUpdate; document::import_notes (0, "$DESKTOP/foo.xml", "", flags); document::show_notes (); document::pdf_export(0, 0, "Druckbare Notizen"); document::hide_notes (0);
return 0; }
static int notes::show(ItemRef docRef = 0)
Show all Comet notes of a given document. Hidden Comet notes to non existing destinations are removed from the document by default.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | valid document 0 : current document |
static int notes::hide(ItemRef docRef = 0)
Hide all Comet notes of a given document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | valid document 0 : current document |
static int notes::get_printable(ItemRef docRef = 0)
Printability* of Comet notes.
*) "Printability" means printing and PFD exports.
Name | Type | Default | Description |
Return | int | Comet notes printable? 1 : yes 0 : no |
|
docRef | ItemRef | 0 | Document 0 : current document Comet_pdf ignores the document and returns the value of the programm option --annot instead. |
static int notes::set_printable(ItemRef docRef = 0, int newState = 0)
Set the printability* of Comet notes.
*) "Printability" means printing and PFD exports.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Document 0 : current document Comet_pdf ignores the document and changes the value of the programm option --annot instead. |
newState | int | 0 | Printability 0 : Do not print or export to PDF 1 : Print and export to PDF |
Toggle the print state of Comet notes.
int main () { int printable = document::get_notes_printable ();
document::set_notes_printable (0, !printable); wlog ("", "# Note printable : %d\n", document::get_notes_printable ());
return 0; }
static int notes::set_pdf_prefs(
float fontSize = 12.0,
char* fontFamily = "Verdana",
int printable = 0,
int opened = 1)
Default setting for PDF comments. See here for information about PDF export and import of Comet Notes
Name | Type | Default | Description |
Return | int | 0 | |
fontSize | int | 12 | Default font size for Comet Notes without local font size settings |
fontfamily | char* oder String | "Verdana" | Default font for Comet Notes without local font size settings |
printable | int | 0 | Make PDF comments printable? 0 : No 1 : Yes |
opened | int | 1 | Open PDF comments in viewer? 0 : No 1 : Yes |
static int notes::change_group(
ItemRef docRef,
int oldGroupID,
int newGroupID)
Transfer Comet Notes from one Comet Group to another Comet Group.
The function was called notes::cometgroup_changed until v4.2 R32064. This old name is still valid.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script document |
oldGroupID | int | - | ID of old Comet group |
newGroupID | int | - | ID of new Comet group |
Create a new Comet Group from the current frame selection and transfer the Comet Notes of an already existing Comet Group to the new group. After that the old Comet Group can be deleted.
int main () { int groupID = 24991; // Put in your Comet Group ID here. ItemList oldGroup = itemlist::get_cometgroup_members (0, groupID, 1); ItemList newGroup = itemlist::selected ();
if (gRun > 1) return 0; itemlist::create_cometgroup (newGroup); document::notes::change_group (0, groupID, itemlist::get_cometgroup (newGroup));
itemlist::remove_items (oldGroup);
return 0; }
static int notes::delete_groupnotes(ItemRef docRef, int groupID)
Delete the Groups notes of a Comet Group.
The function was called notes::cometgroup_deleted until v4.2 R32064. This old name is still valid.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script document |
groupID | int | - | ID of Comet group |
static List notes::find(
ItemRef docRef,
char* selector,
char* regex,
...)
Find Comet Notes.
The function returns a list of note IDs, which for example can be used in functions such as document::notes::delete_note
Search criteria can be passed using an arbitrary number of key value pairs. As keys, any of the selectors listed below can be used, the search value is evaluated as a regular expression.
"title", "A note" finds all notes, whose title contain the phrase "A note".
But "title", "^A note$" finds all notes, whose title is exactly "A note".
To edit notes directly by their document frames or references, use the functions itemlist::doc_notes, ... and frame::notes::change_dest, ... .
Name | Type | Default | Description |
Return | List | List of note IDs matching the given search criteria | |
docRef | ItemRef | - | Document 0 : current script document |
selector | char * | - | identifier for the note field resp. property. Possible values:
|
regex | char * | - | search pattern (regular expression) |
... | char * | - | further selector / regular expression pairs. Search criteria is linked with logical AND |
static int notes::show_note(
ItemRef docRef,
int noteId,
...)
Show particular Comet Notes.
The notes are defined by their IDs (siehe document::notes::find). To edit notes directly by their document frames or references, use the functions itemlist::doc_notes, ... and frame::notes::change_dest, ... .
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script document |
noteId | int | - | ID of the note to be shown |
... | int | - | IDs of further notes to be shown |
static int notes::hide_note(
ItemRef docRef,
int noteId,
...)
Hide particular Comet Notes.
The notes are defined by their IDs (siehe document::notes::find). To edit notes directly by their document frames or references, use the functions itemlist::doc_notes, ... and frame::notes::change_dest, ... .
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script document |
noteId | int | - | ID of the note to be hidden |
... | int | - | IDs of further notes to be hidden |
static int notes::delete_note(
ItemRef docRef,
int noteId,
...)
Delete particular Comet Notes.
The notes are defined by their IDs (siehe document::notes::find). To edit notes directly by their document frames or references, use the functions itemlist::doc_notes, ... and frame::notes::change_dest, ... .
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | document 0 : current script document |
noteId | int | - | ID of the note to be deleted |
... | int | - | IDs of further notes to be deleted |
static int sync::create_variant(
ItemRef docRef,
char* outfileInfo = 0,
int flags = 1)
Create a variant of a sample document. This command is only useful for subsequent document synchronizations.
The command is not executable for new, unsaved documents!
The following steps are performed for the variant:
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | 0 | Document 0 : Current script document The command is not executable for new, unsaved documents! |
outfileInfo | char * oder String | 0 | Path hints for the variant 0 or "" : Place the variant with the suffix _variant next to the master document. relative path : Place the variant under the specified name next to the master document. The name is given without the ending .indd. otherwise : Complete path of the variant |
flags | int | 1 | Flags 1 : Existing variant may be overwritten |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::possible(ItemRef variant, ItemRef master)
Check if a given document can be synchronized with another document. The following prerequisites must be fulfilled for a document synchronization:
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
variant | ItemRef | - | Document reference to the variant 0 : Current script document |
master | ItemRef | - | Document reference to the master |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::before(ItemRef variant)
Prepare a variant for synchronization with the master document. This step must be performed before every \URL[document synchronization]{../InDesign/Plugins/sync_documents.html!} At the end of the synchronization, the function document::sync::after must be executed.
The function sets the XML root element priint_syncDocType to the value in progress. This prevents changes to the variant from being registered as local changes that would prevent subsequent syncs.return int 0 or ErrorCode
Name | Type | Default | Description |
variant | ItemRef | - | Document reference to the variant 0 : Current script document |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::after(ItemRef variant)
The synchronization of a variant is complete. Return the document to its normal state.return int 0 or ErrorCode
Name | Type | Default | Description |
variant | ItemRef | - | Document reference to the variant 0 : Current script document |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::swatches(ItemRef variant, ItemRef master)
Synchronization of swatches. Create missing swatches, tinted swatches and gradient swatches in the variant and update swatches changed in the master in the variant too. Color groups are restored as needed. Shifts to other color groups in the variant are retained. The order of the swatches can change.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
variant | ItemRef | - | Document reference to the variant 0 : Current script document |
master | ItemRef | - | Document reference to the master |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::layers(ItemRef variant, ItemRef master)
Synchronization of layers. Create/update all layers of the master document into the variant. Layers are uniquely identified by their names. The order of the levels remains the same. layers newly added in the variant, which are not contained in the master, are added behind thier original layers form the master. If this layer does not exist (anymore), it is moved to the top.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
variant | ItemRef | - | Document reference to the variant 0 : Current script document |
master | ItemRef | - | Document reference to the master |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::styles(ItemRef variant, ItemRef master)
Synchronization of style definitions. Create/update all styles of the master document in the variant. The command corresponds to the Javascript command doc.importStyles of the InDesign scripting DOM. The following styles are updated:
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
variant | ItemRef | - | Document reference to the variant 0 : Current script document |
master | ItemRef | - | Document reference to the master |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::masterspreads(ItemRef variant, ItemRef master)
Synchronization of master spreads. Create/update all master spreads of the master document in the variant. The command corresponds to the Javascript command doc.loadMasters of the InDesign scripting DOM.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
variant | ItemRef | - | Document reference to the variant 0 : Current script document |
master | ItemRef | - | Document reference to the master |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::pages(ItemRef variant, ItemRef master)
Synchronization of pages. Create/update (the settings) of all pages of the master document in the variant. The link to the original page in the master document is established via the information stored internally on the page (see Javascript function doc.pageGetOrigin.
Pages created locally in the variant (with an Origin == 0) are moved behind the original page. from the master. If this page does not (no longer) exist, the page is moved to the very back.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
variant | ItemRef | - | Document reference to the variant 0 : Current script document |
master | ItemRef | - | Document reference to the master |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::groups(ItemRef variant, ItemRef master)
Synchronization of the frame groups. Create/update all frame groups as defined in in the master document. Groups of the master document have priority over groups of the variant.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
variant | ItemRef | - | Document reference to the variant 0 : Current script document |
master | ItemRef | - | Document reference to the master |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::remove_empty_pages(ItemRef variant, ItemRef master)
Remove empty local pages. Delete all locally created and empty pages of the variant.
Since the variant may contain local changes, it is possible that a page that has been created in the master document is empty, but not in the variant. The variant can also have overridden master spread entries. Pages of the variant with local changes and/or eoverridden master spread entries will not be deleted!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
variant | ItemRef | - | Document reference to the variant 0 : Current script document |
master | ItemRef | - | Document reference to the master |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::remove_empty_layers(ItemRef variant, ItemRef master)
URL[Remove empyt local layers]{../InDesign/Plugins/sync_documents.html#remove_superflous_layers}. Delete all empty layers of the variant that were not created locally and are empty in the master document.
Since the variant may contain local changes, it is possible that a layer that has been created in the master document is empty, but not in the variant. The variant can also have overridden master spread entries. Layers of the variant with local changes and/or eoverridden master spread entries will not be deleted!
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
variant | ItemRef | - | Document reference to the variant 0 : Current script document |
master | ItemRef | - | Document reference to the master |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int sync::cleanup(ItemRef variant, ItemRef master)
Clean up the document after a /URL[synchronization]{../InDesign/Plugins/sync_documents.html}. In the current version, the function removes superflous gradients from object and paragraph styles.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
variant | ItemRef | - | Dokumentreferenz der Variante 0 : aktuelles Skriptdokument |
master | ItemRef | - | Dokumentreferenz des Musterdokumentes |
You can find a complete example in the description of the Document Synchronization:
Example Script
static int metadata::set_title(ItemRef docRef, char* value)
Set the document title. The document title is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : Current document |
value | char* oder String | - | New document title. The new value may be empty (0 or ""). |
static char* metadata::get_title(ItemRef docRef)
Get the documents title. The documents title is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | char* | Title of document.
The return value must not be changed and will be overwritten in subsequent calls of the function. See here to learn more about functions returning r/o char* values. |
|
docRef | ItemRef | - | Valid document reference 0 : Current document |
static int metadata::set_author(ItemRef docRef, char* value)
Set the author of the document. The author of the document is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : Current document |
value | char* oder String | - | New author of the document. The new value may be empty (0 or ""). |
static char* metadata::get_author(ItemRef docRef)
Get the author of the document. The author of the document is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | char* | Author of the document
The return value must not be changed and will be overwritten in subsequent calls of the function. See here to learn more about functions returning r/o char* values. |
|
docRef | ItemRef | - | Valid document reference 0 : Current document |
static int metadata::set_author_title(ItemRef docRef, char* value)
Set the title of the author of the document. The author of the document is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : Current document |
value | char* oder String | - | New title of the author of the document. The new value may be empty (0 or ""). |
static char* metadata::get_author_title(ItemRef docRef)
Get the title of the documents author. The authors title is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | char* | Title of the documents author
The return value must not be changed and will be overwritten in subsequent calls of the function. See here to learn more about functions returning r/o char* values. |
|
docRef | ItemRef | - | Valid document reference 0 : Current document |
static int metadata::set_author_descr(ItemRef docRef, char* value)
Set the document description of the author. The document description of the author is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : Current document |
value | char* oder String | - | New document description of the author of the document. The new value may be empty (0 or ""). |
static char* metadata::get_author_descr(ItemRef docRef)
Get the document description of the author. The document description of the author is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | char* | Get the document description of the author
The return value must not be changed and will be overwritten in subsequent calls of the function. See here to learn more about functions returning r/o char* values. |
|
docRef | ItemRef | - | Valid document reference 0 : Current document |
static int metadata::set_descr(ItemRef docRef, char* value)
Set the author of the document. The author of the document is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : Current document |
value | char* oder String | - | New author of the document. The new value may be empty (0 or ""). |
static char* metadata::get_descr(ItemRef docRef)
Get the description of the document. The description of the document is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | char* | Description of the document.
The return value must not be changed and will be overwritten in subsequent calls of the function. See here to learn more about functions returning r/o char* values. |
|
docRef | ItemRef | - | Valid document reference 0 : Current document |
static int metadata::set_keys(ItemRef docRef, char* value)
Define the keywords for the document. Multiple keywords can be separated by commas. The keywords for the document is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : Current document |
value | char* oder String | - | New keywords for the document. The new value may be empty (0 or ""). |
static char* metadata::get_keys(ItemRef docRef)
Get the defined keywords of the document. Multiple keywords are be separated by commas. The keywords of the document are displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | char* | Defined keywords of the document.
The return value must not be changed and will be overwritten in subsequent calls of the function. See here to learn more about functions returning r/o char* values. |
|
docRef | ItemRef | - | Valid document reference 0 : Current document |
static int metadata::set_copyright(ItemRef docRef, char* value)
Define a Copyright note of the document. The Copyright note of the document is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : Current document |
value | char* oder String | - | Copyright note of the document. The new value may be empty (0 or ""). |
static char* metadata::get_copyright(ItemRef docRef)
Get the copyright note of the document. The Copyright note of the document is displayed in the InDesign File -> File Information... dialog and in the Acrobat menu File -> Properties... of the PDF.
Name | Type | Default | Description |
Return | char* | Copyright note of the document
The return value must not be changed and will be overwritten in subsequent calls of the function. See here to learn more about functions returning r/o char* values. |
|
docRef | ItemRef | - | Valid document reference 0 : Current document |
static int metadata::set_copyright_url(ItemRef docRef, char* value)
Define the Copyright Info URL of the document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : Current document |
value | char* oder String | - | Copyright Info URL of the document. The new value may be empty (0 or ""). |
int main () { // rating // printf ("rating : %d\n", document::metadata::get_rating (0)); document::metadata::set_rating (0, 2); printf ("rating : %d\n", document::metadata::get_rating (0));
// copyright_url // printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0)); document::metadata::set_copyright_url (0, "www.bahn.deppfff"); printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0));
// copyright_state // printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0)); document::metadata::set_copyright_state (0, 2); printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0));
return 0; }
static char* metadata::get_copyright_url(ItemRef docRef)
Get the Copyright Info URL of the document.
Name | Type | Default | Description |
Return | char* | Copyright Info URLof the document
The return value must not be changed and will be overwritten in subsequent calls of the function. See here to learn more about functions returning r/o char* values. |
|
docRef | ItemRef | - | Valid document reference 0 : Current document |
int main () { // rating // printf ("rating : %d\n", document::metadata::get_rating (0)); document::metadata::set_rating (0, 2); printf ("rating : %d\n", document::metadata::get_rating (0));
// copyright_url // printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0)); document::metadata::set_copyright_url (0, "www.bahn.deppfff"); printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0));
// copyright_state // printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0)); document::metadata::set_copyright_state (0, 2); printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0));
return 0; }
static int metadata::set_copyright_state(ItemRef docRef, int value)
Define the Copyright-State of the document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : Current document |
value | int | - | Copyright-State of the document. 1 : Copyright protected 2 : Public Domain otherwise : Unknown |
int main () { // rating // printf ("rating : %d\n", document::metadata::get_rating (0)); document::metadata::set_rating (0, 2); printf ("rating : %d\n", document::metadata::get_rating (0));
// copyright_url // printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0)); document::metadata::set_copyright_url (0, "www.bahn.deppfff"); printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0));
// copyright_state // printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0)); document::metadata::set_copyright_state (0, 2); printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0));
return 0; }
static int metadata::get_copyright_state(ItemRef docRef)
Get the Copyright-State of the document.
Name | Type | Default | Description |
Return | int | Copyright-Stateof the document 0 : Unknown 1: Copyright protected 2 : Public Domain -1 : Error |
|
docRef | ItemRef | - | Valid document reference 0 : Current document |
int main () { // rating // printf ("rating : %d\n", document::metadata::get_rating (0)); document::metadata::set_rating (0, 2); printf ("rating : %d\n", document::metadata::get_rating (0));
// copyright_url // printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0)); document::metadata::set_copyright_url (0, "www.bahn.deppfff"); printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0));
// copyright_state // printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0)); document::metadata::set_copyright_state (0, 2); printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0));
return 0; }
static int metadata::set_rating(ItemRef docRef, int value)
Define the Rating of the document.
Name | Type | Default | Description |
Return | int | 0 or ErrorCode | |
docRef | ItemRef | - | Valid document reference 0 : Current document |
value | int | - | Rating of the document. 1 - 5 : Number of stars otherwise : No rating |
int main () { // rating // printf ("rating : %d\n", document::metadata::get_rating (0)); document::metadata::set_rating (0, 2); printf ("rating : %d\n", document::metadata::get_rating (0));
// copyright_url // printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0)); document::metadata::set_copyright_url (0, "www.bahn.deppfff"); printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0));
// copyright_state // printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0)); document::metadata::set_copyright_state (0, 2); printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0));
return 0; }
static int metadata::get_rating(ItemRef docRef)
Get the Rating of the document.
Name | Type | Default | Description |
Return | int | Ratingof the document 0 : No rating 1 - 5 : Number of stars otherwise : Error |
|
docRef | ItemRef | - | Valid document reference 0 : Current document |
int main () { // rating // printf ("rating : %d\n", document::metadata::get_rating (0)); document::metadata::set_rating (0, 2); printf ("rating : %d\n", document::metadata::get_rating (0));
// copyright_url // printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0)); document::metadata::set_copyright_url (0, "www.bahn.deppfff"); printf ("copyright_url : '%s'\n", document::metadata::get_copyright_url (0));
// copyright_state // printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0)); document::metadata::set_copyright_state (0, 2); printf ("copyright_state : %d\n", document::metadata::get_copyright_state (0));
return 0; }
Alphabetic index HTML hierarchy of classes or Java
